trendsetting technology, worldwide, powered by Online Measurement and Control Solutions ANODE & CATHODE COATING LINES ANODE & CATHODE CALENDERING LINES Battery Industries

Mahlo & Reechi – The Strategic Alliance MAHLO & REECHI – THE STRATEGIC ALLIANCE New Cooperation Mahlo & Reechi – A Powerful Strategic Alliance to Serve the Growing European Battery Market. The new cooperation between Mahlo and Reechi revolutionizes the market for online measurement and control systems for anode/cathode coating and calendering lines. Customers in Europe benefit from many years of experience gathered from thousands of successful installations, sophisticated products, technical application support, excellent after-sales service and a high level of German innovation. Reechi Reechi,...

Scanner types mahlo trendsetting technology, worldwide. X-ray Full Width ■ O-type scanning frame ■ Cathode coating repeatability ± 0.03 g/m2 ■ Anode coating repeatability ± 0.05 g/m2 ■ X-ray can also simultaneously measure the thickness of the thinning area. ■ C-type scanning frame ■ Thinning area thickness measurement ■ Anode / Cathode coating thickness measurement ■ Electrode calendering thickness consistency measurement ■ 100% Full Width Detection ■ Full data traceability ■ Coating thinning zone measurement ■ Various coating defects detection ■ Efficient closed-loop control and adjustment...

Automatic closed-loop control Multi-station counterpoint tracking measurement and data fitting, to system achieve automatic closed-loop adjustment. Closed loop control system Customer benefits Improve adjustment efficiency, and reduce waste. Dual scanning frame all-in-one Synchronised tracking and overlapping of thickness and surface gauge density traces. O-type & C-type scanning frame £ C-type Laser measurement scanning frame (2 O-type X/p-ray measurement scanning frame

mahlo trendsetting technology, worldwide. Product highlights ✓ Core Technologies: Ultra-high signal-to-noise ratio measuring sensor, Measuring software system. ✓ Ultra-high repeating precision: ✓ Various sizes of scanning spots are available: X-ray: 5x5 mm, 4x12 mm, 0 8 mm, ✓ High-speed scanning measurement: The maximum scanning speed can reach 30 m/min. ✓ Multiple measurement methods: Dual-station wide-width measurement, multi-frame tracking measurement, fixed-point tracking measurement, wet film measurement, automatic closed-loop control. ✓ Longer service life of radioactive sources: Prolong...

Technical data TECHNICAL DATA X-ray online measurement system β-ray online measurement system X-ray measuring sensor β-ray measuring X-ray measuring sensor+ sensor Laser displacement sensor β-ray measuring Laser displacement sensor sensor+ Laser displacement sensor O-frame scanner O-frame scanner Marble C-frame scanner Marble C-frame scanner Size Scanning spot Ф 9 mm (X-ray). 20x20 mm (β-ray), 30x1200 µm (Laser) 30x1200 µm (Laser) X-ray & laser integrated machine β-ray & laser integrated machine Laser online measurement system Marble C-frame scanner Applications in the Lithium battery Cathode...

Reference images mahlo trendsetting technology, worldwide. REFERENCE IMAGES Battery Industries 7

trendsetting technology, worldwide, powered by Monitoring and control systems, automation Best-possible technical support and know-how transfer are written in capital letters at Mahlo. Thanks to an international network of agencies and service centres, customers have at their disposal competent support worldwide. We are there for you. Just get in touch with us! ✓ Service partners in over 100 countries ✓ Direct on-site service and fast delivery of spare parts ✓ Remote diagnostic system Mahlo GmbH + Co. KG - Germany Donaustr. 12 93342 Saal / Donau Telephone: +49-9441-601-0 Fax: +49-9441-601-102...
