Overview: This document provides detailed technical information on manifolds and valve packs, specifically focusing on cover plates used in hydraulic systems. It includes specifications, materials, and part number systems for various cover plate models.

Specifications:

Cover plates are used to block off bar manifold port connections and are available in parallel and series models.
Standard materials include Aluminum and Ductile Iron, with optional materials like Mild Steel or Stainless Steel.
Special finishes such as Black Oxide, Electroless Nickel Plating, or Anodizing are available.
UNC or Metric mounting bolt kits and Viton O-rings are supplied as standard.
Optional gauge ports are available on pressure ports, which may require increased thickness of the cover plate.

Part Number System:

Each cover plate type (D02, D03, D05, D05H, D05HE, D07, D08, D10) has a specific part number system that includes codes for type, material, valve pattern, circuit, gauge port, and mounting.
Examples are provided for each cover plate type, illustrating how to construct part numbers based on the desired specifications.

Key Features:

Internal passages are maximized to match interface port connections.
Special D05D valve pattern matches both D05H and D05HE.
Cover plates with external ports for relocating valves are available upon request.
Special combinations of ports, including X & Y ports, are non-standard and require factory contact for part numbers.
Servo cover plates are available and require factory contact for part numbers.
