Camera Specifications Overview
The document outlines the specifications for Lumenera's INFINITY series digital microscopy cameras, detailing models INFINITY1, INFINITY2, INFINITY3, INFINITY4, and INFINITYX. Each model is tailored for specific applications, offering different resolutions, sensor types, and features.

INFINITY1 CMOS Cameras
These cameras provide 1.3, 3.1, and 5.0 megapixel resolutions, ideal for documentation and archiving. Key features include auto white balance, full exposure control, and programmable gain.

INFINITY2 CCD Cameras
Available in 1.4, 2.0, and 3.3 megapixel resolutions, these cameras offer higher dynamic range and low noise electronics, making them suitable for scientific and medical applications.

INFINITY3 Cooled CCD Cameras
Designed for low light applications, these cameras feature cooling to 25ºC below ambient, improving the signal-to-noise ratio.

INFINITY4 Large Format CCD Cameras
With a 10.7 megapixel resolution, these cameras use large format sensors for high fidelity color reproduction.

INFINITYX High Resolution CMOS Cameras
These cameras offer resolutions up to 21 megapixels, utilizing sub-pixel shifting technology for high-resolution image archiving.

Software and Compatibility
All cameras come with INFINITY ANALYZE software for advanced image acquisition and analysis, and are compatible with Mac OS via a plug-in.

OEM Custom Camera Design
Lumenera provides custom camera development for OEM customers, offering options to enhance time to market and reduce development costs.

Interface Comparison
The document compares USB 2.0 and FireWire interfaces, emphasizing USB 2.0's plug-and-play capability and adequate throughput for image sensors.

Technical Specifications
All cameras support USB 2.0 interface, offering plug-and-play capability. Frame rates vary by model and resolution, with USB 2.0 providing 480 MBIT/S throughput. Features include auto/manual exposure, white balance, programmable gain, and region of interest capabilities. Operating temperature ranges from 0ºC to +50ºC with humidity tolerance of 5% to 95% non-condensing.

Applications
The cameras are suitable for various applications including brightfield, darkfield, DIC, live cell imaging, histology, pathology, cytology, semiconductor inspection, metrology, and fluorescence applications.
