LUMtL www.lumel.com.pl

• destined to measure: d.c. current and voltage, a.c. current, a.c. voltage, temperature, • display: 4 or 5 digits (red), digit height: 20 mm (N24) and 14 mm (N25), • legible unit on the meter housing, • configuration through the PD14 programmer and the free LPConfig program, • programming possibility: decimal point position, measurement averaging time and individual indication characteristic, • supply of object transducers (24 V d.c.), • protection grade from the front: IP65, • overall dimensions: 96 x 48 x 64 mm. • destined to measure: a.c. current, a.c. voltage, d.c. current, d.c....

• destined to convert into a standard analog signal: - a.c. current and voltage (P20Z), - d.c. current and voltage (P20, P20H, P17), - temperature (P20, P17), • destined to separate inputs, outputs and auxiliary supply, and match analog signals in automation systems (P17G, P20G), • supply: 85...253 V a.c./d.c. or 20...50 V a.c./d.c., (P20, P20Z, P20H, P20G) • supply from a current loop (P17) • supplied from input (P17G), • possible programming of ranges and the type of sensor using the PD14 programmer and the free LPConfig program (P20,P20H, P20G), • overall dimensions: - 22.5 x 120 x 100...

• destined to measure: - voltage, current, active, reactive and apparent power, cos, , tg, frequency, • counting of active and reactive energy, imported and exported, and capacitive and inductive energy, • output: digital RS-485 - MODBUS protocol, relay and pulse, • 15-minutes’ power control, so-called „power guard”, • detection and signaling of incorrect phase sequences, • configuration through the free LPConfig program, • supply: 85...253 V a.c./d.c. or 20...50 V a.c./d.c. • overall dimensions: 96 x 96 x 70 mm. • destined to measure: - voltage, current, active, reactive and apparent...

• destined for temperature control or other physical quantities, • input: - dedicated (RE71), - versatile – thermocouples, resistance thermometers or standard signals (RE72), • programmed control – 15 programs of 15 segments (RE72), • output: relay or logic for SSR control, • control algorythm: - on/off with hysteresis, SMART PID (RE71, RE72), • manual setting of PID parameters or by means of the autotuning function, • digital output RS-485 with MODBUS protocol (RE72), • IP65 housing protection grade, • overall dimensions: 48 x 48 x 93 mm. • destined for temperature control or other...

• recording and measurement of electric and non-electric quantities, • LCD TFT 5,7’ colour screen, 320 x 240 pixels, with a touch panel, • recording and data archiving on a CompactFlash 4 GB card, • protection grade from the front: IP65, • 3 or 6 (KD8), 3, 6, 9 or 12 (KD7) analog measuring inputs, • 24 channels for data transmitted through the communication interface (KD7), • 16 or 32 alarms and 8 or 16 digital inputs (KD7), • 6 or 12 alarms and 4 or 8 digital inputs (KD8), • visualization of measurements in analog or digital indicators, bargraph and chart diagram forms, • interfaces:...

• modules of analog inputs (2 inputs) – SM1, (4 inputs) – SM2 • module of logic and pulse inputs (2 inpuls) – SM3 • module of logic inputs (8 inputs) - SM5 • module of logic outputs (8 outputs OC type or 4 relays) – SM4 • interface: RS-232 and RS-485, Modus protocol, • supply: 230 V or 24 V a.c/d.c • fixing on a 35 mm rail, • overall dimensions: 22,5 x 120 x 100 mm (SM1,SM3), 45 x 120 x 100 mm (SM2, SM4, SM5) • radio transmission modules in the non-licensed band (SM7,MR03): - transmission frequency in bands: 433 and 868 MHz (SM7), - transmission frequency in band: 868 MHz (MR03), - power up...

• destined to measure: - d.c. current and d.c. voltage (MA series), - a.c. current and a.c. voltage (EA series), • direct ranges: - from 40 ìA to 25 A and from 60 mV to 1000 V (MA series), - from 100 mA to 100 A and from 6 V to 1000 V (EA series), • accuracy class: 1.5, • exchangeable scales, • co-operation with shunts, current and voltage transformers, • IP65 protection grade (optional for MA16, MA17, MA17P, MA19, MA19P, EA16, EA17, EA19), • overall dimensions: 48 x 48, 72 x 72, 96 x 96, 144 x 144, 72 x 24, 96 x 24 mm. • destined to measure: - d.c. current and d.c. voltage (MB16), - a.c....

• destined for contactless power switching, • output current from 10 A to 50 A, • load voltage: 230 V a.c. or 400 V a.c., • application in 1 and 3-phase networks, • impulse control steering voltage: 0/3 ... 32 V d.c. • destined for a smooth power control in single-phase networks, • output current from 5 A to 125 A, • maximum load supply: 440 V, • analog or pulse control, • phase control, • switching on at zero voltage or in any time, • overall dimensions: 135 x 231 x 199 mm (RP1), 50 x 105 x 105 mm (RP7). • destined for three-phase actuators in control systems and for automatic temperature...

• wide-ranging advisory services, preparation and realisation of automation systems on the base of LUMEL’s devices and devices from other manufacturers, • design, modernization and execution of automation and measuring systems, • completion of automation and measuring systems, • programming, implementation of control and visualization industrial process systems, • programming of automation and measuring systems realizing compatible functions with technological guidelines and customer’s requirements, • setting in motion and testing of automation and measuring systems, • training of customers...

LUMEL S.A. – we are one of leading European manufacturers of electrical devices for automation and high pressure aluminium castings. We have been on the market since 1953. We have achieved our high position on the market due to continuous development policy, competence of our employees and modern equipment for research, design and production. The activity of LUMEL S.A. is focused on 4 main branches: • production of automatic devices for measurement, conversion, control and recording, transmission and visualization of various industrial processes; • production and machining of high pressure...
