Lowara NewZ6 Series Stainless Steel Submersible pumps for 6 wells >

The extensive use ofstainless steel for the main partsin contact with the pumped liquidminimize the risk ofwater contamination. You drink the water as at the source You drink the water as at the source >

■ The hydraulic design results in the which reduces the length (lessstages) maximum pressure per stage and weight of the pump: Robust design- Easy to handle! ■ prevents and The delivery head protects made of the pumpfrom precision cast Stainless Steel water hammer and ensuresa rigid and safe connection tothe pipe. ■ For an easy connection to thesafety rope the delivery head is equipped with two safety hooks and two locking screws for thepipe to ensure your pump is always secure. ■ ensures a The motor adapter robust and rigidconnection made of precision cast Stainless Steel to the motor ● available...

■ A combination of using tungsten carbide bearings, floating wear rings andprotection of the shaft by the stainless steel sleeves ensures the bestresistance to sand abrasion. ■ The design of the impellers manufactured in pressed Stainless Steelminimizes themomentum of inertia of the pumps ensuring a minimumtorque requirement of the motor during the starting phase: longer lifeof the motors! ■ The Strips are designed to resist the maximum pump pressure and give thebest stiffness to the unit. APPLICATIONS ■ Municipal watersupply ■ Irrigation ■ Mines ■ Fire fightingBooster sets ■ Golf Turf Irrigation...

Precision casthead Safety hook - easyto connect the safetyrope - high protection againstwater hammer andensures a rigid andsafe connection to the delivery pipe Safety screws tolock the delivery pipe Bearing made of Tungsten Carbide Integrated nonreturn valve that ensures the bestshaft alignment in the worst conditions Integrated up thrustbearing Modular design Suction part of theimpeller withremovable wear ring - with limited parts -easy to maintain low costmaintenance Improved design of the shaft grooves for easyand fastdisassembling The pump shaft isprotected by theStainless Steel spacers Removablecoupling...

■ Increased Life Cycle Cost - lowerenergy consumption ■ No water contamination Nopaint,no rust ֢֠ High sand handling capability 100 g/m > 3 ■ High pressure per stage - shorter pumps - Easy to handle andinstall ■ Modular design - easy and fast tomaintain / repair ■ Pump water from deep wells(700 m) ■ Robust design - delivery head andmotor connection made of castStainless Steel ■ Easy to connect - delivery connectionstandard 2 > 1 / > 2 -3Ԕ available 3 and4Ԕ NPT AND MORE ■ Different high grade materials available ■ High pressure pump (above 550 m head) reinforced by outer sleeve ■ Complete range...
