Open the catalog to page 1Corporate Capabilities Application Engineering ■ Application Engineers with a combined 65 years of ■ Unmatched ability to suggest proper foot control for customers' needs ■ Second to none in offering custom products ■ Daily interface between customers and vendors ■ Agency expertise (UL, CSA, CE, WEEE, RoHS, FDA) Customer Service ■ Customer Service Representatives with a combined 55 years ■ Estimated 110,000 hours of direct interface with customers ■ Servicing accounts worldwide ■ Defined and dedicated territories to establish a rapport with ■ Direct human interface ■ Real time data...
Open the catalog to page 2Custom Medical OEM Switches That custom foot switch you need may already have been designed. Illustrated are but a few of the custom foot switches we have manufactured to meet the specific needs of the Original Equipment Manufacturer. Whether you are looking for a standard model or a custom foot switch designed to your specifications, be sure to contact LINEMASTER. Let us know the details of your foot switch specifications for a prompt quotation. Remember, our many years of experience in designing and making foot switches, will save you time and money and avoid costly design pitfalls.
Open the catalog to page 4Custom Industrial OEM Switches Special variations are only available to the Original Equipment Manufacturer (O.E.M.) in production quantities. Specials are made to the O.E.M.'s specifications, and orders for specials are accepted on a direct basis only. Any modification to a standard item, however slight, i.e. minus the nameplate, would be considered a special. We offer custom cordset service, so that we can provide a complete foot control assembly to the O.E.M.'s specifications. Special paint finishes, nameplates, mounting provisions and packaging are some of the options available to the...
Open the catalog to page 5Special Variations - Original Equipment Manufacturers Special Variations are only available to the Original Equipment Manufacturer (O.E.M.) in production quantities. Specials are made to the O.E.M.'s specifications, and orders for specials are accepted on a direct basis only. Any modification to a standard catalog item, however slight, i.e. minus the nameplate, would be considered a special. We offer custom cordset services, so that we can provide a complete foot control assembly to the O.E.M's specifications. Special paint finishes, nameplates, mounting provisions and packaging are some of...
Open the catalog to page 6USE OF FOOT CONTROLS ON MACHINERY LACKING EFFECTIVE POINT OF OPERATION SAFEGUARDS CAN CAUSE SERIOUS Foot controls should only be used where "Point of Operation" and "Pinch Point" guarding devices have been properly installed and are utilized so that it is IMPOSSIBLE for the operator's hands or fingers to remain within the point of operation during the machine cycle. POINT OF OPERATION-The point or area of the machine or equipment where the work piece or material is actually positioned and work is being performed during any process such as cutting, shearing, punching, forming, welding,...
Open the catalog to page 8Driptight • Dusttight • Watertight • Oiltight GUARDED, COMPACT & WATERPROOF DESIGN ■ One Piece Cast Aluminum Housing Single Stage Momentary Contact ■ Aluminum baseplate on unguarded models ■ Single Pedal 1/2"-14 N.P.T. Threaded Conduit Opening is Standard ■ Twin Pedal 3/4"-14 N.P.T. Threaded Conduit Opening is Standard Features & Benefits: ■ Non-Skid Feet To Minimize Movement ■ Divider Bar on Twin Models aids in Reducing Accidental Operation of Multiple Pedals at Once ■ 4 holes provided for rigid mounting to floor or equipment ■ Heavy Gauge Steel Full Guard painted Alert Orange Covering...
Open the catalog to page 26Driptight • Dusttight • Watertight • Oiltight MEDIUM DUTY COMPACT DESIGN ■ Cast aluminum body and treadle with steel base plate and nonskid base pad ■ Single 34"-14 N.P.T. threaded conduit entry is standard Features & Benefits: ■ All models single stage momentary contact ■ 2 holes provided for rigid mounting to floor or equipment Options: ■ Special threaded conduit entry available to the O.E.M. on special order (Dual / Metric) ■ Single/Dual 1/2 In. -14 NPT threaded conduit entry ■ Metric threaded conduit entry
Open the catalog to page 28Dusttight • Watertight • Oiltight • Corrosion Resistant MILITARY GRADE DESIGN ■ Rugged aluminum casting is painted gray ■ Piston type actuator sealed with O-rings ■ 1/2"-14 N.P.T. threaded conduit entry. Features & Benefits: ■ Electrical contacts are sealed in a "well" ■ Corrosion resistant housing & components ■ 3 mounting holes provided for rigid mounting to floor or equipment Options: ■ Non-skid basepads available ■ Custom colors - Special Order
Open the catalog to page 32Aquiline® Maintained - Polymeric EN 60529 Degree of Protection IP20 (IP68 Upon Request) Corrosion Resistant VERSATILE COMPACT DESIGN ■ SPDT, DPDT, Two-Stage, Momentary or Maintained Operation ■ Rustproof and corrosion proof reinforced polymeric material cover and formed steel base ■ Raised ribs on treadle for positive traction during operation ■ Integrated adjustable strain relief clamp accommodates cord sizes from .250 Dia. to .400 Dia. Features & Benefits: ■ Maximum versatility, total performance ■ 2 holes provided for rigid mounting to Floor or equipment Options: ■ Custom colors, and...
Open the catalog to page 39Treadlite II - Stainless Steel Driptight • Dusttight • Watertight • Corrosion Resistant (Available) COMPACT VERSATILE LOW PROFILE DESIGN ■ Stainless Steel housing with brushed finish Features & Benefits: ■ Nonskid base pad and foot treadle pad ■ The low profile and light pressure required to operate reduces operator fatigue Options: ■ Stainless Steel Full Guard Available (See "Accessories - Guards" on page 75 for details)
Open the catalog to page 44Driptight • Dusttight • Watertight HIGH IMPACT LOW PROFILE OMNI-DIRECTIONAL DESIGN ■ Actuation from any direction with moderate pressure ■ The cover and base is molded in a high impact polymeric compound ■ Base includes mounting provisions Features & Benefits: ■ Low profile to aide in elimination of fatigue ■ Wired normally open, no ground Options: ■ Stainless Steel Weight Plate Available ■ Custom Cable Available ■ Available in RED in Production Quantities INTENDED FOR INDOOR USE PRIMARILY TO PROVIDE A DEGREE OF PROTECTION AGAINST THE ENTRY OF WATER DURING OCCASIONAL TEMPORARY SUBMERSION AT...
