Letatwin 2022 - Brochure

Product catalog summary

Overview: The LM-550A2 series is a portable printer designed for control panel wire numbering and device labeling. It supports various print media including grip tubes, heat shrink tubes, ID plates, and self-adhesive tapes.

Specifications: The printer accommodates different tube sizes and materials, such as halogen-free tubes compliant with IEC61249-2-21 standards. It supports polyester tapes in widths of 5, 9, and 12mm, and markable slide plates.

Features: The printer includes a half-cut feature for polyester tapes, useful for labeling control panel devices. It supports a range of wire sizes from 0.5mm² to 16.0mm², with specific tube recommendations for each size.

Materials: The grip tube is designed for easy stop and multi-wire diameter tubing. The 'N' tube series is UL224 certified, offering high insulation performance. The drum roll design ensures smooth feeding in the Letatwin printer.

Recommendations: It is advised to verify the compatibility of wire and tube sizes, as the recommended sizes do not guarantee a perfect match. The printer's versatile print media allows for easy positioning and movement of markers on wires.

Catalog excerpts

PORTABLE PRINTER FOR CONTROL PANEL WIRE NUMBERING & DEVICE LABELLING • Grip Tube • Heat Shrink Tube • Self-adhesive Tape

Open the catalog to page 1

VERSATILE PRINT MEDIA GRIP TUBE Easy stop & Multi wire diameter tubing(sleeve) Specially designed tube, helps your markers hold a fixed position on the wire, even when using multiple wire diameter sizes. This material is a good fit to ferrule terminals. 1 Holds Position Inside Shape Push into sleeve pocket *HALOGEN FREE : Accordance with IEC61249-2-21,Cl Polyethylene Plate for Sleeve pocket. Break by hand 0.09wt% , Br 0.09wt%, total content rate of both is 0.15wt% R0UND TUBE Vinyl(PVC) for Half-cuttable feature by LETATWIN `L`Tube (Vinyl(PVC)/Drum Roll/No UL) The drum roll design allows the tube...

Open the catalog to page 2
