Leonardo Sistemi Integrati S.r.l. Leonardo Sistemi Integrati S.R.L. Via Greto di Cornigliano, 6r 16152 Genova GE www.leonardo-si.it

index FLD Fuel Level Display LLC Laser Level Control ATS Anti Theft System DLC Dynamic Level Contol Level Mesaurement

The new cost-effective DISPLAY for real-time, on-site monitoring of tankers and fixed tanks The FLD-04 DISPLAY monitors up to five tanks. Monitoring parameters for each tank can be freely set via the backlit color graphic display. The display mirrors all configured parameters and a dynamic image of the levels on a smart device, even from a long distance. The dedicated App is included free of charge. lECEx and ATEx certifications for use in Zone 1 areas. Safety barriers for Zone 0 sensors are included. Also available in a non-ATEx version. • Backlit LCD display showing product volume/level and...

Phisical parameters continuously updated: • Volumes (tank-tables level to volumes) Special probes can be used, on customer request, to measure other FLD uses high precision level probes in order to provide also the water presence inside the tank (in case of fraud)

• Fuel level inside the tank. • Volume of fuel inside the tank (the product volume is computed against "tank tables" (level-to-volume). • Two user-defined alarms can be chosen (ex: pre-minimum and minimum). • Alarms sending, without SIM, via MFF2 very economical Connection system. It uses the best connection platform of the tank installation area. • Geo-localized position on map of each tank in order to have an immediate view of the position of the alarmed tank (ex.: minimum level). It allows a prompt refilling without any blackout of the tank service. • Silent and periodical check of the level...

LASER LEVEL CONTROL - LLC The transmission and the data reading take place through an LSI portal open to the customer. Different choice on request of the customer can be implemented. The LLC is powered by a solar panel. It can be pulled out (till 2-4 mt far) in An additional integrated longlife battery (2 years minimum) can feed the LLC in case of need The LLC can be personalized on customer request.

ATS 01 - ANTI THEFT SYSTEM Active radio-controlled Sealing The ATS-01 is a robust electronic system for the remote sensing of sealing opening and is designed to work on fixed sealing. The System is based on a central unit connected to a patended sealing system with up to 15 RFID unique code tag, continuously read by the central unit by a main dorsal cable. Points to be sealed can be decided by the customer on the base of Manipulation, damaging, cutting heating of one of the tags, causes its own non response to the reading of the central unit. An immediate alarm is generated and the involved tag...

The ATS System has been designed to trasmit its data to a concentrator that sends them to the corporate portal. The data concentrators can be the DLC System (see above) or the navy system already installed on board The System fits very welll also the transport of dangerous pollutants liquids when the total safety (best pratice) is required against occasional or intentional spillages. ATS is the perfect and ideal anti-froud System to be coupled with the DLC System. So the whole auto-tank safety can be • The System can be personalized on customer request.

DLC - DYNAMIC LEVEL CONTROL BB The Systems performs a continuous and highly accurate reading of the • Volume/level inside the cisterns of the fuel trucks • Seals alarm in association with ATS System (see below) • Jamming alarms For each level sensor, DLC supplies a georeferenced real time product-volume computed against "tank tables" (level-to-volume). Data can be checked also by single Fuel truck, by single cistern, by single trip, by single period and by volume variation in litres The System takes in account the tank tilt angle

Its integrated water detection and measurement function makes an additional crucial contribution to quality assurance and to fight frauds. The Systems can be configured up to ten level sensor for ten cisterns and two density sensors (different configurations can be implementated). The DLC is provided with an active Ex Antenna suitable for GPS and others worldwide trasmission systems. The remote server application can be easily installed on user premises or on cloud logical space

LEVEL MEASUREMENT SYSTEMS PROCESS LEONARDO SISTEMI INTEGRATI has a partnership with FAFNIR We distribute the FAFNIR TG robust systems specially built for the Process Industry Precision, accuracy, flexibility and long life characterise our level, overfill and density probes range.

Leonardo Sistemi Integrati S.r.l. Marketing & Sales Director Oil&Gas-Process-Industry Divisions E-mail [email protected]
