Plastic catalogue

Catalog excerpts

No reproduction or use without express permission of editorial or pictorial content, in any manner. Printed in Switzerland, 2008 Pdf updated, February 2011

 Open the catalog to page 2

Since it’s creation in Switzerland in 1946 the LEMO Group has been recognized as a global leader of circular Push-Pull connectors and connector solutions. Today LEMO and its affiliated companies, REDEL and COELVER, are active in more than 80 countries with the help of over 40 subsidiaries and distributors. The modular design of the REDEL range provides over 5’000 connectors from ø 14 mm to ø 21 mm, capable of handling cable diameters up to 9.5 mm and up to 32 contacts. This vast portfolio enables you to select the ideal connector configuration to suit almost any specific requirement in most...

 Open the catalog to page 4

The REDEL connectors are plastic Push-Pull connectors. These circular plastic connectors are especially adapted for applications such as medical electronics and test & measurement. REDEL offers a wide choice of connectors with various contact configurations: multipole contacts, coaxial, fibre optics and fluidic connectors. In addition, a range of one time use connectors and connectors for mains power is available. The REDEL connectors are available in 3 sizes, depending on the cable diameter. œ Medical electronics œ Test and measurement œ Industrial electronics œ Automotive œ Aesthetically...

 Open the catalog to page 5

4 Exploded view of the REDEL 1P Straight plug Straight plug with bend relief Fixed socket Note: the bend relief must be ordered separately. backnut cable collet insulator + contacts shell bend relief backnut for a bend relief cable collet insulator + contacts shell Free socket hexagonal nut front nut backnut cable collet insulator + contacts shell shell

 Open the catalog to page 6

6 A well proven connector of a small size to accomodate cable diameter up to 6.5 mm and allow up to 14 solder contacts. Top quality lightweight and rugged materials have been chosen to optimize most applications. Poly sul fone (PSU), UL certified as auto extinguishable, can be sterilized by gas or by steam. The contacts are gold-plated over copper and nickel to ensure at least 1000 mating/ unmating cycles without significantly affecting the electrical characteristics. A keying system combined with colour coding can be incor porated on most connector models to assist in the prevention of...

 Open the catalog to page 8

7 Plug P A G M 0 2 G L A C 3 9 A Model: (pages 8-18) Keying: (page 20) Variant Z = cable collet and nut for fitting a bend relief Cable fixing type: C = cable collet Contact type: (page 20) A= male to solder C= male to crimp L = female to solder 2) Collet nut colour table: (page 20) G = grey N = black A = blue R = red J = yellow V = green B = white Insulator: L = PEEK Outershell: Number of contacts: (page 19) Collet: 39 = (cable ø 2.7 mm - 3.9 mm) 52 = (cable ø 4.0 mm - 5.2 mm) 65 = (cable ø 5.3 mm - 6.5 mm) Contact configuration (page 19) Part numbering system PAG.M0.2GL.AC39A Straight...

 Open the catalog to page 9

8 Standard models (IP50) P .M . . 2 4 3 1 5 1 6 7 2 8 9 1 Outershell 2 Insulator 3 Female contact 4 Hexagonal nut 5 Front nut Fixed socket Straight plug ø 14 ~30 ~45 PAG Straight plug, key (G) or keys (A, B, C, H and J), with cable collet Part Number PAG.M•.•GL.AC39G PAG.M•.•GL.AC52G PAG.M•.•GL.AC65G min max 2.7 3.9 4.0 5.2 5.3 6.5 Cable ø S 9 ~28.7 ~48 ~43.7 ø 14 PAG Straight plug, key (G) or keys (A, B, C, H and J), with cable collet and nut for fitting a bend relief Part Number PAG.M•.•GL.AC39GZ PAG.M•.•GL.AC52GZ PAG.M•.•GL.AC65GZ min max 2.7 3.9 4.0 5.2 5.3 6.5 Cable ø Value Standards...

 Open the catalog to page 10

10 M14 x 1 19.5 20 mini 20.5 2 4 A A 9 maxi S17 S12.5 L PKG Fixed socket, key (G) or keys (A, B, C, H and J), with two nuts, with 90° contacts (back panel mounting) Note: for PCB drilling pattern see page 25. Panel hole see page 24. Part Number L PKG.M0.2GL.VG PKG.M0.4GL.VG PKG.M0.5GL.VG PKG.M0.6GL.VG PKG.M0.7GL.VG PKG.M0.8GL.VG PKG.M0.9GL.VG PKG.M1.0GL.VG PKG.M1.4GL.VG 2 5.4 4 5.2 5 7.7 6 7.7 7 7.7 8 7.7 9 10.3 10 10.3 14 12.9 M14 x 1 25 N a 4 S12.5 PMG Fixed socket, key (G) or keys (A, B, C, H and J), with square flange Solder + Crimp M14 x 1 25 N 4 S12.5 c ød 1 Print Part Number...

 Open the catalog to page 12

11 ø 14 ~40 PRG Free socket, key (G) or keys (A, B, C, H and J), with cable collet Note: replace •.• by contact configuration (see page 19). Part Number PRG.M•.•GL.LC39G PRG.M•.•GL.LC52G PRG.M•.•GL.LC65G min max 2.7 3.9 4.0 5.2 5.3 6.5 Cable ø ~43 ~38.7 S 9 ø 14 PRG Free socket, key (G) or keys (A, B, C, H and J), with cable collet and nut for fitting a bend relief Note: replace •.• by contact configuration (see page 19). The bend relief must be ordered separately (see page 22). Part Number PRG.M•.•GL.LC39GZ PRG.M•.•GL.LC52GZ PRG.M•.•GL.LC65GZ min max 2.7 3.9 4.0 5.2 5.3 6.5 Cable ø ~40 9...

 Open the catalog to page 13

12 Elbow socket models (IP50) P . . . ø 13.4 3 14.5 14.8 30.2 18.5 14.8 15.9 ø 13.4 PPG Elbow socket, key (G) or keys (A, B, C), for printed circuit Part Number PPG.M0.2GG.N PPG.M0.4GG.N PPG.M0.5GG.N PPG.M0.6GG.N PPG.M0.7GG.N PPG.M0.8GG.N PPG.M0.9GG.N PPG.M1.0GG.N Note: only available with G or A, B, C keying. The insulator is made of PSU. Outershell material is grey or black PSU. For PCB drilling, see page 25. 14.5 14.8 30.2 19.2 4 6.9 maxi S17 S12.5 3 18.5 M14x1 14.8 15.9 M14x1 6.9 max. 4 PXG Elbow socket, key (G) or keys (A, B, C), with two nuts, for printed circuit Part Number Note:...

 Open the catalog to page 14

5 cycles IEC 60512-5 test 9a -30/+90°C – ABS – 13 Disposable plug (limited use) P J .M . A A.A T 3 8 B 46.5 ø 5.3 ø 14 ø 12 PJG Straight disposable plug Note: only G, A, B, C keying available. Only ABS plastic shell. White standard (B) or grey optional (G) Cables up to 3.8mm diameter. Available only with male solder contacts. Delivered in blister packs. Part Number PJG.M0.9AA.AT38B PJG.M1.0AA.AT38B PJG.M1.4AA.AT38B 9 0.85 PKG.M0.9GL.LG 10 0.85 PKG.M1.0GL.LG 14 0.60 PKG.M1.4GL.LG Recommanded Mating fixed socket part number nb. of cts. Test Voltage (kV rms) Disposable socket (limited use) a...
