MINIATURE FIBER OPTIC CONNECTORS COELVER

Product catalog summary

Overview: The COELVER 01 series miniature fibre optic connectors are designed for high-density applications, featuring a 1.25 mm ceramic ferrule for superior mechanical, environmental, and optical performance. The connectors are suitable for telecom, datacom, and digital broadcasting applications.

Specifications: The connectors utilize a self-latching Push-Pull system for quick installation. They are compatible with DIN 41612 connectors using special adaptors. The connectors are designed for use with 900 µm plastic buffered fibre and 2-3 mm simplex semi-tight jacket cables.

Mechanical and Environmental Characteristics: The connectors have a mating durability of 500 cycles and can withstand temperatures from -40°C to +85°C. They are tested for cable retention of 100 N and can endure damp heat conditions at +40°C and 93% RH.

Optical Performance: The multimode insertion loss is 0.13 dB, and the singlemode insertion loss is 0.07 dB. Return loss for PC polishing is greater than 25 dB, and for UPC polishing, it is greater than 45 dB.

Materials and Treatment: The connectors are made from brass, beryllium copper, ceramic, stainless steel, and copper, with specific treatments applied to enhance durability and performance.

Tools and Accessories: The document lists various tools and accessories, including crimping tools, polishing tools, and fibre inspection microscopes, necessary for assembly and maintenance.

Assembly Instructions: Detailed instructions for cable assembly and connector installation are provided, ensuring proper setup and usage.
