Overview
Leine & Linde specializes in creating durable and reliable encoder solutions for challenging environments, providing precise feedback on speed and position. Their encoders are designed to function efficiently under extreme conditions, ensuring long-term reliability and minimal maintenance.

Product Series

1000 Series - Extreme: Built for extreme temperature, mechanical forces, and vibrations, featuring high encapsulation levels and stainless steel options.
800 Series - Heavy Duty: Known for robustness, suitable for heavy industries like steel and paper, with advanced diagnostics for condition-based maintenance.
700 Series - Compact: Offers robustness in a compact design for installations with limited space but requiring heavy-duty performance.
600 Series - Industrial: Absolute position encoders for single or multiturn movements, suitable for industrial automation with advanced fieldbus interfaces.
500 Series - Robust: Versatile and modular, conforming to European standards, available in hollow or solid shaft designs.
300 Series - Miniature: Reliable miniature encoders for applications with restricted space.

Key Features

Precision: Focus on accuracy and quality, delivering fault-free products on time.
Confidence: Building long-term client relationships by providing reliable encoders for tough environments.
Flexibility: Customizable solutions with around 10,000 variants, developed in collaboration with customers.

Applications

Wind Turbines: Controls generator rotation speed and positions tower and rotor blades.
Paper Industry: Ensures accurate speed regulation of rollers to avoid costly production stoppages.
Steel Industry: Controls speed of roll motors and adjusts roll heights in extreme environments.
Cranes: Positions winch and wheels for safe load lifting, adjusting motor speed based on load weight.

Technical Specifications
Encoders feature interfaces like SSI, EnDat, PROFIBUS, and more, with options for incremental and absolute signal outputs. They withstand high levels of vibration and shock, with encapsulation levels up to IP67.

Conclusion
Leine & Linde encoders are engineered for precision, reliability, and adaptability, suitable for a wide range of industrial applications. Their commitment to quality and customer collaboration ensures products meet high standards of performance and durability.

600 Series - Absolute Encoders
Features robust ø58 mm encoders with increased vibration resistance, supporting single or multiturn movements and communicating via SSI, EnDat, PROFIBUS, PROFINET, or CAN interfaces. Specifications include a diameter of 58 mm, vibration resistance of 300 m/s², shock resistance of 2000 m/s², and an encapsulation level of IP67, operating in temperatures from -40 to +100 ºC.

500 Series - Versatile and Modular Encoders
Offers versatile and modular encoders conforming to European standards, suitable for electric motors, cranes, elevators, and general automation. Includes various models with different resolutions and electronics options, customizable with thousands of variants.

300 Series - Miniature Encoders
Consists of robust miniature encoders for space-restricted applications like mobile machinery, with a diameter of 30 mm, vibration resistance of 300 m/s², shock resistance of 5000 m/s², and an encapsulation level of IP67, supporting incremental electrical interfaces like TTL and HTL.

Accessories
Leine & Linde offers accessories for installation and extended functionality, including shaft couplings, connectors, mounting kits, and gateways for signal adaptation, ensuring high-quality performance and compatibility.

Contact Information
Contact details for Leine & Linde's regional offices and distributors worldwide, emphasizing their global presence and support network.
