Strainers Overview
This document provides technical specifications and design details for industrial strainers, focusing on two main types: standard strainers and basket strainers. The strainers are designed for various industrial applications, with specific attention to pressure handling, screening fineness, and construction materials.

Standard Strainers

Designed for industrial applications with service pressures up to 12 bar.
Features large screening surfaces and easy handling.
Screening fineness is color-marked: 0.6 mm (white), 0.3 mm (blue), 0.2 mm (red).
Constructed from robust materials with a slim design.
Available in various sizes with BSPP connections ranging from 1/2 to 3 inches.

Basket Strainers

Designed for high flow volumes and low pressure loss, with a maximum pressure of 8 bar.
Equipped with a flow deflector to prevent obstruction and allow easy removal of dirt particles.
Prepared for connection of two pressure gauges to monitor pressure loss.
Screening surface area is 860 cm² with a screening insert diameter of 145 mm and height of 320 mm.
Available with various screen insert types and mesh sizes, including 500 µm/32 mesh, 360 µm/50 mesh, 170 µm/100 mesh, and 135 µm/120 mesh.

Technical Specifications

Material options include Polypropylene and Monel for different components.
Ordering numbers are provided for different configurations based on type, size, and material.
Pressure loss charts and correction factors are included to assist in selecting the appropriate strainer for specific applications.
