Laser Mechanisms is proud to introduce Tippy Gasjet as their official ambassador of laser beamdelivery information. Tippy provides helpful tips and explanations that are meant to offer a better understanding of the complex concepts surrounding laser beam delivery.Look for Tippy throughout The Laser Mechanisms Catalog and Sourcebook of Laser BeamDelivery providing a wealth of useful information. >

Abeam delivery system is what turns a laser into a functional tool. Except in extre-mely rare instances, a laser by itself is a useless device without a means to transport the beam to a workpiece and to transform, condition, manipulate, shape and focus it along the way.Beam delivery systems can be thought of as being either mirror-based ( conventional beam delivery )or fiber-based ( fiber-optic beam delivery or FOBD). Fiber-optic beam delivery is not presently pos-sible with CO transmission , reflectivity and absorption .The chart below shows where the wavelengths for various types of...

Once a particular laser has been chosen for an application, the function of a beamdelivery system is to: Direct the beam from the output of the laserto the work-piece Ֆ Typical components include Beam Benders, MountingPlates, Beam Shuttles, FOBD systems and Articulated Arms. Control (orchange) the size and shape of the beam Ֆ Typicalcomponents include Collimators, Beam Expanders and Telescopes. Control (orchange) the polarization of the energy in thebeam Ֆ Typical components include Polarizers, Phase Shiftersand Phase Retarders. Focus the beam Ֆ Typical components include Lens Holders,Lens...

Most phenomena in physics are described as either being particle-based or wave-based.Light is unique in that it exhibits both particle behavior (transmission, reflectivity, absorp-tion) and wave behavior (polarization, mode, diffraction). Fairly early in the history of laser cutting a phenomenon was discovered whereby the cutting rate wasslower and the the cut kerf width was wider in one direction than in an opposing direction. This became understood to be attributable to the factor of polarization , or the direction of the energy inher-ent in a laser beam. Fortunately, once understood,...

Phase Shifter MirrorsDiameterThickness inch (mm)inch (mm) PLIRC0004 1.0 (25)0.125 (3.125) > 45 PLIRC0005 1.0 (25)0.25 (6.25) > 45 а PLIRC0002 1.5 (37.5)0.16 (4) > LINEARPOLARIZED PLIRC0003 2.0 (50)0.375 (9.375) > BEAM IN POLARIZEDCIRCULAR BEAM OUT Cut Quality EnhancersPLCQE0001 Two-mirror (optics not included) PLCQE0048 For Coherent Diamond lasers PLCQE0067 Two-mirror (optics not included) water-cooled Feedback IsolatorsPLFBI0006 For Coherent Diamond lasers PLFBI0011 For Rofin SC30 lasers > Once the polarization is under control, its properties can also be put to use for other purposes.One...

Beam divergence is the measurement of the increase in beam diameter over distance,usually expressed in milliradians (take care to note whether the specification is half angle or full angle both expressions are commonly used). Although lasers characteristically have low diver-gence, in certain applications it is critical to collimate the beam (that is to make the light rays parallel)and reduce or eliminate divergence. This is particularly important when the beam is used at long dis- tances from the laser; when the beam path length changes as in a flying optic system and when the beam exits a...

CO-AXIAL OFF-AXIS WITH ZOOM 90 DEGREE OFF-AXIS, NO ZOOM

Shorter focal length lenses produce smaller spot sizes and higher power densi-ties at the focus point, but may be limited by a shallower Plano-convex beam waist lenses areeconomical and are the most widely used. ) is defined asa range within +/- 5 to 10 percent of the focus spot size. Longer focal length lenses produce longer depths of field and are particularly useful for thick material cutting and deep hole drilling.ՕLens shape helps to achieve precise focusing and con-tain spherical aberrations. depth of focus andincreased spherical aberrations . Other drawbacks are increased...

ҕThere are both theoretical limits and (more realistically) practical limits as tohow small a beam of light can be focused. The first limit is that the beam cannot be focused smaller than the wavelength (example: 10.6 microns for CO > 2 and 1.06 microns forNd:YAG). The next limit (which makes the above purely academic) is diffraction .Diffraction is an inescapable, natural result of the wave nature of light, which causes energy tospread transversely (across the beam) as the beam propagates (similar to lightՒs particle nature of divergence). Diffraction is proportional to wavelength (so once...

Quite often in the world of laser processing, the answer to any question begins withthe qualifier, That depends onӅ Although at first this typical response may seem frustrat-ing, the truth is that a successful laser application is interdependent on a variety of factors.Once the basic principles are well understood, they are not that difficult to utilize into extremely pro-ductive results. Over the years, many users have developed reliable, repeatable laser processes, and many of these para- meters are now well known and shared in the applications community. Manufacturers of lasers and...

Being more than just a supplier of components and assemblies, Laser Mech offers Expert Solutions that encompass a full understanding of your application and process,and the expertise to provide complete systems. Often this includes the use of electrical or electronic devices to perform manipulation of the laser beam or beam delivery components, and to integrate full functionality with the total laser machine.Using the same high quality standards of competent design engi-neering and precise fabrication methods that go into our mechani- cal and optical components, Laser Mech produces several...

Complete line of lenses, nozzles, power metersand front-end head component parts From Laser Mechanisms, the most trusted name inquality laser beam delivery components for over 20 years, comes Laser Mech Replacement Parts & Service (RPS), your new full-line industrial laser spare parts supplier. With access to Laser MechanismsՒover 300 years of collective engineering experience, Laser Mech RPS is not just another noz- zle clearinghouse. We know laser systems and what it takes to keep them operating at peak efficiency.Enhanced services of Laser Mech RPS include: Immediate shipment of spare...
