Pioneering Industrial and IP Networks Product Guide

Industrial Ethernet Switches Applications Contents Contents About Lantech Transportation Power and Utilities Maritime / Ship / Offshore Platform Oil and Gas Surveillance Building Automation and Security Process / Manufacturing Automation Mining EN50155 Business Ethernet Switches Technology Pro-Ring System Lantech-View Industrial Entry Switches Industrial Smart-Ring Switches Industrial Managed Switches Industrial DNV Type Switches Industrial IEC 61850 Switches Industrial EN50155 Switches Industrial Converters Series Industrial PoE Series Industrial Device Server Managed Switches Smart...

About Lantech About Lantech P1 With a long background in IP Ethernet products, Lantech brings the best network solutions for Industrial and IP networks to the marketplace. The Lantech group is devoted to providing feature rich, high-quality networking solutions with outstanding service and support to our world-wide partners. Lantech’s core competency is centered around our network software and hardware, which allows for the seamless delivery of a variety of applications and services in diverse network environments. Lantech products are integrated with Pro-Ring, our proprietary auto network...

To become a modern country, countries worldwide are constantly developing and improving their transportation systems. Transportation systems commute people and goods within city and between cities as basic country infrastructure to prosper economic growth. Therefore, devices in a transportation network need to be durable for different operating environments and have immediate reaction responding to control center. Lantech products are able to apply in transportation applications for trains, buses, MRTs, trams, cars, and highways, providing total network solutions, including surveillance,...

Train Monitor and Control The train control system not only adjusts the speed of trains, but also provides information of the whole railway system, including each vehicle’s status such as the anti-skid system status, hotbox, brake cylinder condition, the train pipe pressure, smoke alarm, power supply, lighting, chargers, leakage protection, electrical safety record, air-conditioning unit operating conditions, temperature, and the inside door status. The status are transferred via network and displayed in digital data, LED light and digital meter, providing each system’s status more...

Applications Power and Utilities For Lantech Arrivied 2010 1/16 Sunday P4 The current power grid technology has been using for over 100 years in which it has very low efficiency accounts 67% power lost in total power generation resulting big economic lost. In order to fulfill the “Copenhagen Climate Summit” goal reducing 20% to 40% of green house gas by 2020, smart grid network by two way digital technology has become essential to deliver, store, allocate for resilience energy integrating from solar and wind power. Advantages of Smart Grid A basic power grid consists of several parts. A...

Applications P5 Pro-Ring <10ms Human Interface Device Computer Workstation RTU IP Camera IES-2224-PU IES-2224-PU IES-2224-PU IES-2224-PU IED IED SCADA Master IP Phone Network Managers have complete control of remote IEDs and are alerted to changing system conditions. When an incident occurs, the nature of the problem can be quickly determined via a Human Machine Interface (HMI) and appropriate corrective action is able to be taken, without having to send personnel to the remote substation. Often corrective action is taken automatically without human intervention. Data for monitoring the...

Applications Maritime / Ship / Offshore Platform For Lantech Arrivied 2010 1/16 Sunday P6 Challenges of Maritime Application Marine network applications are divided into two categories – One is On-shore, the other is Off-shore. On-shore applications include Lighthouse surveillance, Wind turbine controlling and monitoring systems, Tide Power controlling and monitoring systems and surveillance. Off-shore applications include IP networking for Oil platforms, Battleships, Yachts, and Cruise Liners. The challenges of marine network applications include coping with harsh environmental conditions....

Applications P7 DHCP Server DHCP Server Control Room Pro-Ring Pro-Ring Pro-Ring Fiber UTP Deck A Deck B Deck C LES-2400-RPS IEC-0101FT-DNV IES-2208F-DNV IES-2216C-DNV Marine Ships- Tough Conditions Challenge I Vibration When a ship starts its engine, the vibration can cause equipment to fail. For battleships, the vibration caused by firing missiles is so intense, that it can cripple electronic equipment on-board ships. The vibration strain test that DNV carries out takes from 90 to 120 minutes and operates three perpendicular plans (different frequency / amplitude) to reveal the most...

Applications Oil and Gas For Lantech Arrivied 2010 1/16 Sunday P8 Human Interface Device Computer Workstation Web Server IP Phone Wellhead RTU IP Camera Lantech PLC (Programmable Logic Controller) IP Phone Pro-Ring <10ms IES-2307C IES-2307C IES-2307C Giga Fiber UTP IPES-0005T-4 IPES-0005T-4 To other area The whole oil and gas industrial system starts from wellhead, which may be divided into on-shore and off-shore, and ends with the refine system. Between wellhead and refine factory is the distributed system such as pump station and pipeline. Operating environments of oil and gas industry...

Applications P9 Oil and gas are transmitted via pipelines and pump stations. In order to ensure high and uniform flow of oil, pump stations are needed at regular intervals and pipelines must be under control. For example, to keep the pressure in the pipeline at 50 bar pressure, managers must monitor the status continuously. The reliable Ethernet network allows manager monitor the pressure and flow constantly, making it possible to detect and locate leaks of the pipeline. The entire station data is collected from the individual pump stations, via the extensive Ethernet networks, to a central...
