Product program
40Pages

Our hallmark: Reliability and precision covering the complete range Tool and mould makers are working at the highest levels of milling technology. From single workpiece to high volume production you will find a solution for your application in our product range.Users from different industrial areas point great demands to LANG machines. Precision, speed, reliability and efficiency are required and for more than 30 years they can count on us. This applies to tool and mould manufacturing as well as for sectors where you have to label by engraving (milling cutter or laser), for the printing...

IMPALA 400 S, 560 S, 800 S > - CNC milling and engraving machines 8 IMPALA 200, 400, 800 > - CNC milling and engraving machines 10 RM 800 S, 1200 S, 1500 S > - Special cylindrical milling and engraving machines 12 LGR-S / LGT-S > - CNC 4 axis milling and engraving system for engraving tire side wall moulds 14 LDIGIT 300 > - Digitizing system 16 SU-2 > - Precision cutter grinder 17 > LErgoCAD 19 Reliefdesigner light 20 Reliefdesigner 21 LDriver 22 LTire 23 > Win-Commander 25 ECO-MOT 26 ECO-STEP 27 LSTEP PCI-compact 28 LSTEP 29 LSTEP PP 30 LStep-44 / LNC COMPACT 31 LEA 32 API 33 Accessories...

In case of high precision machining, when very fine and detailed structures are requested, companies worldwide from different industries feel confident in the innovative technologies of our organisation. > - Special tooling for pressing the coins for mints worldwide as currency - Minting industry worldwide use our special equipment to manufacture the tools for pressing coins for currencies and medals - The biggest coin made out of gold was manufactured by Austria Mint with our IMPALA 400 machine. > - Special tooling for watermarks and other security details for banknotes and security papers >

Graphic, printing and packing industry > - Embossing dies- Embossing cylinders - Printing cylinders - Cutting cylinders - Hot foil cylinders Toy industry > - Plastic injection moulds - Aluminium casting moulds Automotive industry > - Tire sidewall moulds - All kinds of stamps for marking and lettering

- Plastic injection moulds- Aluminium casting moulds - Hot runner technology - Forming dies > - Regulating pistons for hydraulic cylinders - All kind of marking and lettering > - Replacement teeth made out of ceramic material >

Medical industry > - EDM-electrodes Optical industry > - Laser marking of glasses and lenses- High precision CNC controlsfor microscopes and grinding machines for lenses Jewelry industryand others >

CNC milling and engraving machines with servo motor control > Sg) IMPALA 400 S The IMPALA S-series with servo motor control is our answer to the requirements of the market. The IMPALA S-series carries up-to-date drive and control technology as the basis for high speed machining. These machines offer solutions for a productive high speed machining of coated steel (up to HRC64) as well as non hardened steel, stainless steel, plastic, brass, copper, graphite, wood, etc. . IMPALA 400 S > Working range X x Y x Z 480 x 380 x 180 mmoptional: extended X-axis Clamping area 640 x 540 mm Feed rate 10...

IMPALA 400 IMPALA 400IMPALA 200 This exceptionally versatile series of machines literally leaves the competition between a rock, in this case granite, and a hard place.The machines are based on a solid granite design for optimal absorption of vibration and temperature fluctuation.The result is the highest possible production quality. > Working range X x Y x Z 300 x 200 x 200 mm Clamping area 540 x 260 mm Feed rate, inside material 1,3 - 2,6 m/min Feed rate, outside material 2,6 - 5,2 m/min Load bearing capacity (work piece and accessories) 150 kg Max. acceleration 0,14 m/s Spindle speed...

IMPALA 800Reliefs, dies, relief double dies, cutting and embossing cylinders... in other words, everything from signs to cylinders made of any number of different materials, including stainless steel, can be produced quickly and economically and with utmost precision on the IMPALA.A comprehensive range of accessories is available to customise this multi-purpose machine to meet your individual requirements >

RM 800 S The professional machine for the production of cutting and embossing cylinders, especially for machining operations where numbers of tools are required.The rotary axis and the tail stock can be adjusted along the whole front of the machine, providing a high flexibility in the choice of work pieces. The machining axis are driven by high precision ball screws in connection with AC servo drives.RM 800 S and RM 1200 S can be upgraded to 4 axes. > Working range X x Z 720 x 250 mm Working range Y (optional) 15 mmDiameter of cylinder 10 - 320 mmFeed rate 30 m/min Load bearing capacity 400...

LGR-S The LGR-S and LGT-S are ultraprecision machines for engraving 2D and 3D data on tire sidewall moulds. The machine body is a heavy-duty, torsionfree, tubular steel construction filled with a vibration reducing compound for an extremely high stability. Tire sidewall moulds for tires for motorbikes, cars, trucks, and even oversized special vehicles can be produced to the highest quality on the LGR-S / LGT-S. The machines will be driven by high dynamic AC servo drives. > Largest work piece diameter to be clamped 2.200 mm Largest work piece diameter to be engraved 2.200 mm Diameter of the...

LGT-S With LTIRE, the software program for this special application, you can completely design a tire sidewall mould with speed and high efficiency. > Largest work piece diameter to be clamped 1.400 mm Largest work piece diameter to be engraved 1.200 mm Diameter of the rotary table faceplate 1.200 mm Permitted load on the rotary table 3.000 kgWorking range, C-axis (rotary table) 360 Working range, X-axis 500 mm Working range, Z-axis 400 mmTraversing angle B-axis б 90Spindle output 0,3 - 2,6 kW Speed range 5.000 - 60.000 rpm Traversing speed up to 15 m/min Weight of the machine 4.500 kg >
