PULL STUDS
Product catalog summary
Overview: The document provides detailed specifications and descriptions of various types of pull studs used in machining applications. Pull studs are essential components that connect the tool holder to the machine spindle, ensuring secure and precise tool positioning.
Specifications:
- MAHO OTT Pull Studs: These are specified for use with MAHO OTT systems, with various angles and configurations available.
- Deckel Pull Studs: Designed for use with Deckel systems, allowing compatibility with DIN 69871 or MAS-403 BT shanks.
- JIS B 6339 Pull Studs: These studs are specified with a 15° angle, adhering to the JIS B 6339 standard.
- MAS 403 BT Pull Studs: Available in angles of 45°, 60°, and 90°, with options for coolant through channels.
- DIN 69872 - ISO 7388/2 Pull Studs: These are specified with a 15° angle, available in Form A and Form B, with and without coolant channels.
- ISO 7388/2 Pull Studs: Available in 45° configurations, with options for coolant channels.
- CHIRON ISO 30 Pull Studs: Designed for CHIRON tool holders, available in short and long configurations.
Key Parameters:
- Angles: Pull studs are available in various angles (15°, 45°, 60°, 90°) to suit different machine and tool holder requirements.
- Coolant Channels: Some pull studs are designed with coolant through channels to facilitate cooling during machining operations.
- Thread Sizes: Various thread sizes (e.g., M-12, M-16, M-24) are specified to match different tool holder and machine spindle configurations.
Recommendations:
- Ensure compatibility between pull studs and machine systems (e.g., MAHO OTT, Deckel, CHIRON).
- Select pull studs with appropriate angles and thread sizes for specific machining applications.
- Consider pull studs with coolant channels for operations requiring enhanced cooling.
Limitations:
- Some pull studs do not comply with specific standards (e.g., MAS 403-BT, ISO 7388/2 Form B), which should be noted during selection.
