1. Material and Manufacturing Specifications

The modular boring heads and tooling components are made from case-hardening alloy steel, case-hardened and tempered to a minimum core strength of 880 N/mm², with surface hardness between Rc 57 and 60. Threads are ground for precision fit. Proper cleaning and lubrication before assembly are emphasized to ensure functionality and longevity.

2. Product Categories and Descriptions

• Universal Arbors: For milling cutters with longitudinal or tenon drive (DIN 138), diameters 16–50 mm.
• Collet Chucks (ER Type, DIN 6499): Sizes ER16 to ER40, for cylindrical straight shanks (DIN 1835-A), with maximum circular deviation ≤ 0.005 mm.
• Stub Arbors: For plain mills with longitudinal keyway (DIN 138), sizes 16–32 mm.
• Drill Chuck Arbors: Adapted for DIN 238 or JACOBS drill chucks, sizes B12-B18 and J3.
• Arbors for Reamers: Diameters 18.5–63 mm, lengths 10–50 mm.
• Reducing Adapters: For tanged Morse taper tools (DIN 228-B) or threaded Morse taper tools (DIN 228-A), diameters 23–90 mm, circular deviation ≤ 0.008 mm.
• Modular Extensions and Reducers: Diameters 14.5–90 mm, including front contact extensions and reducers for screw-in tools (not interchangeable with LAIP/C.O. systems).
• Adapters to Other Modular Systems: Compatible with KAISER, CAD, and KOMET systems, diameters 23–90 mm.
• Boring Bars and Heads: Short boring bars (DIN 6385 Form C), micrometric fine boring heads for finishing, double cutter heads for roughing.
• Specialized Tool Holders: Weldon and whistle-notch end mill holders, tapping chucks with self-feed and compression systems, toolholder blanks.

3. Dimensional and Quality Standards

• Strict control of circular deviation: ≤ 0.008 mm for arbors and adapters, ≤ 0.005 mm for collet chuck housings.
• Additional tapped holes for front clamping per DIN 2079 on some components.
• Standardized thread sizes and pitches (e.g., M10x1.5, M12x1.75, M14x2) ensure modular compatibility.

4. Accessories and Optional Components

• Balanced nuts (standard) and bearing nuts (optional) for collet chucks.
• Special rings to fix angular position of cutting tools enhance precision.
• Wrenches and assembly tools referenced for proper installation.

5. Assembly and Maintenance Recommendations

• Thorough cleaning and lubrication before assembly are critical for correct fit and function.
• Use of special rings and balanced nuts recommended to maintain precision and extend tool life.

6. Ordering and Identification

• Components identified by specific codes indicating size, type, and optional features.
• Detailed tables provide dimensions including diameters, lengths, thread sizes, and options.
• Cross-references to accessory pages facilitate comprehensive ordering.

7. Compatibility Notes

• Some screw-in extensions and reducers with front contact are not interchangeable with LAIP or C.O. modular tooling systems.
• Adapters enable connection between LAIP modular tooling and other systems such as KAISER and CAD.

Boring Bars and Tooling Components Overview

1. Boring Bars for RIGIBORE and MICROBORE Cartridges

Diameters from 22 mm to 181 mm, lengths 9–12 mm, featuring a 53º 8' angle and dial scale graduated at 0.01 mm radius for precise adjustment. Special rings available for angular positioning. Cartridges supplied on request.

2. Adapters for SANDVIK COROMANT Inserts

Diameters 80–250 mm, lengths 9–13 mm, facilitating use of standardized inserts to expand tooling versatility.

3. Micrometric Fine Boring Heads

For finishing, diameters 23–153 mm, lengths 9–14 mm, with high-precision radial adjustment screw graduated at 0.01 mm diameter. TORX screws clamp rhombic inserts. Special angular positioning rings available.

4. Double Cutter Boring Heads

Designed for roughing, offering increased rigidity via larger contact surfaces. Integrated coolant outlets and optional setting gauge for diameter pre-adjustment. Diameters 23–153 mm, lengths 9–15 mm. Special rings for angular positioning included.

5. Insert Holders for Double Cutter Heads

Available in 70° and 90° variants. The 70° holders maximize use of all four cutting edges of rhombic inserts, improving tool life and cutting efficiency, with rigid clamping and unobstructed chip flow.

6. Micrometric Fine Boring Heads (Small Diameter)

Diameters 3–53 mm, lengths 9–17 mm, designed for finishing with special angular positioning rings. Detailed tool and sleeve dimensions provided.

7. Weldon and Whistle-Notch Holders

For end mills with DIN 1835-B and E shanks, diameters 6–32 mm, maximum circular deviation 0.005 mm. For diameters ≥ 25 mm, two clamping holes ensure secure holding.

8. Tapping Chucks and Quick-Change Tapping Chucks

Support taps M3 to M28 with axial compensation for compression and extension, plus a release mechanism preventing rotation unless spindle reverses, aiding precise tapping depth control, especially in blind holes. Quick-change versions compatible with BILZ adapters cover taps M3 to M30.

9. Toolholder Blanks

Diameters 14.5–90 mm, lengths up to 90 mm. Critical zones treated to withstand 700 N/mm²; rest hardened to Rc 57–60. Include centering point per DIN 332 Form-R.

10. Rings for Angular Positioning of Boring Heads

Special rings for diameters 14.5–90 mm allow precise angular corrections at 90° and 180° increments, improving tool alignment and machining accuracy.

Critical Information and Best Practices

• Use angular positioning rings for precise tool alignment and repeatability.
• Dial scales graduated at 0.01 mm enable fine diameter adjustments for high-precision boring.
• Double cutter heads enhance rigidity and productivity in roughing.
• 70° insert holders maximize rhombic insert cutting edge usage, extending tool life.
• Tapping chucks with axial compensation and release mechanisms facilitate accurate threading, especially in blind holes.
• Toolholder blanks are hardened and precisely centered for durability and accuracy.
• Integrated coolant outlets improve chip evacuation and tool life.

Technical Codes and Dimensional Data

The document includes codes such as 05 01, 020 54 02 06 01, 020 54 02 07 01, and 020 54 02 08 01, likely representing part numbers or categories. Diameter values (D1) range from 65 to 170 mm. An optional length parameter (L1) is noted, and a consistent angular measurement of 270° (L) is applied across entries, indicating a standard angular specification for components or operations. This data supports component specification and assembly instructions.

Summary

This document is a comprehensive technical catalog detailing modular boring heads, bars, adapters, holders, and accessories designed for precision machining. It emphasizes high-quality materials, strict dimensional tolerances, modular compatibility, and includes detailed specifications, ordering codes, and best practices to support accurate selection, assembly, and maintenance of tooling for boring and milling operations.
