COLLETS & TAPPING ADAPTERS

Product catalog summary

Overview: This document outlines the specifications and applications of various collets and tapping adapters, detailing their design, materials, and relevant standards.

Collets Specifications:

DIN 6388 Collets: These collets are available in Forms A, B, and E, suitable for plain and threaded straight shank tools. They are constructed from tempered spring steel with a hardness of 56-58 HRc.
DIN 6499 (ER Type) Collets: Designed for plain cylindrical straight shanks, these collets come in sealed and non-sealed versions, made entirely from steel, and are compatible with tools that have or do not have coolant channels.
ER Shrink Fit Extensions: These are adaptable to ER-32 collet chucks and are suitable for carbide, cermet, and HSS tool shanks.

Tapping Adapters:

Quick Change Tapping Adapters (Bilz Type): These adapters are available with or without torque release clutches and are suitable for light machining tasks.
DIN 6328 Tapping Collets: These are designed for tools with cylindrical straight shanks with square DIN 10.

Technical Data:

Assembly and Removal: The document provides instructions for assembling and removing DIN 6499 and DIN 6388 collets, highlighting the importance of proper tool shank coverage.
Concentricity: It specifies the maximum deviation allowed based on precision class standards.

Ordering Information: Each product section includes a coding system for ordering, specifying material and hardness, with examples provided for clarity.
