CILINDRICAL

Product catalog summary

Overview: This document provides technical specifications and descriptions for various machining tools and accessories, including universal arbors, boring bars, reducing adapters, extension collet chucks, shrink fit extensions, and short drill chucks. It includes detailed measurements, material specifications, and compatibility standards.

Specifications:

Universal Arbors: Designed for milling cutters with longitudinal or tenon drive according to DIN 138. Available in sizes ranging from 16 to 32 mm.
Boring Bars: Used for holding cutting tools, with specifications for different diameters and lengths.
Reducing Adapters: Compatible with tanged Morse taper tools (DIN 228-B) or threaded Morse taper tools (DIN 228-A). Sizes range from 20 to 32 mm.
Extension Collet Chucks (ER Type): Conform to DIN 6499 standards, available in sizes ER11 to ER40. Maximum circular deviation is ≤ 0.003 mm.
Shrink Fit Extensions: Suitable for carbide, cermet, and HSS tool shanks according to DIN 6535 form HA and DIN 1835-1 form A. Includes a built-in bored through stop screw.
Short Drill Chucks: Integral design with specifications for various diameters and lengths.

Material and Hardness:

Tools are made from case-hardening alloy steel, case-hardened and tempered, with a minimum core strength of 880 N/mm² and surface hardness of Rc 57 to 60.

Additional Features:

Optional accessories such as wrenches and balanced nuts are available.
Custom sizes and profiles can be requested.

Standards and Measurements:

All tools adhere to specific DIN standards for compatibility and performance.
Detailed measurements for each tool type are provided, including diameter, length, and thread specifications.
