Economic Double Layer Shaking Incubators 2020

Product catalog summary

Overview: The LABWIT double layer shaking incubators are designed for modern biological engineering departments, offering a large capacity for flasks with a small footprint. These incubators are ideal for fermentation and pharmacy experiments, as well as for mixing large amounts of liquid at a constant temperature.

Design and Capacity: The incubators feature a compact design with two trays stacked vertically, doubling the capacity for smaller flasks. The top tray can be removed to accommodate larger flasks on the bottom tray, with a shaking frame upgrade required for this configuration.

Features:

Microprocessor controller with audible and visual alarms for precise temperature and speed control.
User-friendly control panel for easy digital setting of time, temperature, and speed.
Large LCD display showing actual and preset parameters.
Electronic timer with automatic stop and audio/visual alarm.
Password protection against unauthorized parameter changes.
Non-volatile memory for set point retention after power interruptions.
Large double-fold tempered glass window with fluorescent lights for chamber visibility.
Auto-defrosting system for long-term non-frosting operation at low temperatures.
Brushless AC motor for smooth, quiet, and uniform shaking motion.
High-quality #304 stainless steel interior for durability.
Lockable outer door for security (specific models).
UV light for contamination-free chamber.

Specifications:

Models: ZWY-1102C, ZWY-2102C, ZWY-1102, ZWY-2102, ZWY-1112B, ZWY-2112B, ZWF-1112, ZWF-2112.
Volume: Ranges from 170L to 580L.
Shaking Mode: Orbital or Reciprocal.
Temperature Range: A +5 to 60°C or 4 to 60°C.
Temperature Accuracy: ±0.1°C.
Temperature Uniformity: ≤±1°C at 37°C.
Speed: 30-300 rpm (some models 30-240 rpm).
Power: Ranges from 1000W to 1950W.
Electricity: 220-240V, 50/60 Hz.
Approval: CE, ISO certified.

Ordering Information: Various models and accessories are available, including frames, trays, clamps, and tube racks, with specific part numbers for ordering.

Note: LABWIT's quality assurance program involves continuous assessment and improvement, and specifications may change without notice. For more details, contact LABWIT or their representatives.

Catalog excerpts

Economic Double Layer Shaking Incubators 2020-1

ZWY-2102C Description: These LABWIT double layer shaking incubators are specially developed for the modern biological engineering departments; a big capacity of flasks but with small footprint. These incubators have a smooth compact design. They are very efficient and have an excellent floor space/performance factor. Two trays above each other, double the capacity for smaller flasks, while after removing the top tray, big flasks can also be used on the bottom tray (Shaking frame upgrade required). These unit are particularly ideal for fermentation and pharmacy experiments. While they are also widely used where a big amount of liquid needed to be mixed at with constant temperature. Double Layer Shaking Frame Features: • Microprocessor controller with audible and visual alarms maintains precise temperature and speed control. • Users friendly control panel allows easy digital setting of time, temperature and speed. • Large LCD display presents all actual and preset parameters. • Electronic timer, from 0 - 500 hours, automatic stop, audio/ visual alarm. • Password protection against unauthorized change of parameters. • Audible and visual alarms for over-temperature and set point deviations. • Non-volatile memory for set point retention after a power interruption. • Large double-fold tempered glass window, together with fluorescent lights provides complete visibility of chamber interior. • Auto-defrosting system, ensuring long-terms non-frosting operation with low temperature setpoint • "Long-Life" brushless AC motor creates a smooth, quiet and uniformed shaking motion. • Mirror-finished high quality #304 stainless steel for excellent durability of interiors. • Standard shaking frame and standard stainless steel tray included, but without clamps. • Vertical double trays for big capacity, though small footprint. • Lockable outer door (on ZWY-1112B/2112B. ZWF-1112/2112) protects the materials against unauthorized access at all times, e New uv light reduces the air burden, keeping the chamber contamination free.

Open the catalog to page 1

Economic Double Layer Shaking Incubators 2020-2

Specifications: Model Shaking Mode Temperature Accuracy Temperature Uniformity Inner dimensions (mm) (WxDxH) Exterior dimensions (mm) (WxDxH) Packing dimensions (mm) (WxDxH) Ordering Information: Part NO. ZWY-1102C, 170L, Economic Double Layer Shaking Incubator A+5-60, 30-300rpm ZWY-2102C, 170L, Economic Double Layer Shaking Incubator 4-60, 30-300rpm ZWY-1102, 330L, Economic Double Layer Shaking Incubator A+5-60, 30-300rpm ZWY-2102, 330L, Economic Double Layer Shaking Incubator 4-60, 30-300rpm ZWY-1112B, 580L, Economic Double Layer Shaking Incubator A+5-60, 30-300rpm ZWY-2112B, 580L, Economic...

Open the catalog to page 2
