PARAM XLW (EC) Auto Tensile Tester
1 /3Pages

PARAM XLW (EC) Auto Tensile Tester

PARAM XLW (EC) Auto Tensile Tester
1 /3Pages

Catalog excerpts

PARAM XLW (EC) Auto Tensile Tester-1

PARAM® XLW (EC) Auto Tensile Tester XLW (EC) Auto Tensile Tester can be used to measure tensile, peeling, deformation, tearing, heat sealing, adhesive, puncture force, opening force and low speed unwrapping force as well as other performance of plastic films, composite materials, soft package materials, plastic flexible tube, adhesives, adhesive tape, label stickers, medical plasters, release paper, protection films, combined caps, aluminum foils, diaphragms, back sheets, non-woven fabrics, rubber and paper. Professional Technology • Better than 0.5% of full scale effectively ensures accurate test results • Supports bidirectional testing modes including stretching and compression and test speed could be adjusted freely • 8 independent test modes are available, including tensile strength, peeling force, tearing force, heat sealing and other performance test • Different test range of load cells and 7 distinct test speeds to meet different test requirements • Pneumatic clamping system provides the even clamping force for specimen to ensure the accuracy of test results • Intelligent designs of over-travel protection, overload protect and automatic position reset for safe test operation • Professional operating software supports statistical analysis of group specimens, and export test results in different units • Supports Lystem™ Lab Data Sharing System for uniform and systematic management of test results and test reports High-end XLW (EC) utilizes Labthink's latest embedded computer system, with better performance than traditional single chip one. • Embedded computer control system integrates control software with the instruments together • Professional control system provides safer and more reliable data management as well as test operation • The instrument can be easily operated by a mouse, a keyboard, and a monitor; without requiring a PC. • The instrument is equipped with four USB ports and dual Internet ports for convenient data transmission. Applications This instrument is equipped with more than 100 grips for tests of more than 1000 materials. And customization is also available for special material tests. Examples of instrument applications: Labthink Instruments Co., Ltd. 144 Wuyingshan Road, Jinan, P.R.China (250031) Phone: +86-531-85068566 FAX: +86-531-85062108 Labthink International, Inc. 200 River's Edge Drive, Medford, MA, 02155, U.S.A. Phone:+1-617-830-2190 FAX: +1-781-219-3638 www.labthink.com

 Open the catalog to page 1
PARAM XLW (EC) Auto Tensile Tester-2

Test Standards This instrument conforms to multiple standards including: ISO 37, ASTM E4, ASTM D882, ASTM D1938, ASTM D3330, ASTM F88, ASTM F904, JIS P8113, GB 8808, GB/T 1040.1-2006, GB/T 1040.2-2006, GB/T 1040.3-2006, GB/T 1040.4-2006, GB/T 1040.5-2008, GB/T 4850-2002, GB/T 12914-2008, GB/T 17200, GB/T 16578.1-2008, GB/T 7122, GB/T 2790, GB/T 2791, GB/T 2792, GB/T 17590, QB/T 2358, QB/T 1130 Labthink Instruments Co., Ltd. 144 Wuyingshan Road, Jinan, P.R.China (250031) Phone: +86-531-85068566 FAX: +86-531-85062108 Labthink International, Inc. 200 River's Edge Drive, Medford, MA, 02155, U.S.A....

 Open the catalog to page 2
PARAM XLW (EC) Auto Tensile Tester-3

Technical Specifications Specifications Load Cell Capacity Test Speed Specimen Width Clamping Way Gas Supply Gas Supply Pressure Stroke Instrument Dimension Power Supply Net Weight _XLW (EC)_ 500 N (standard) 50 N (optional) Better than 0.5% FS Forward 50 100 150 200 250 300 500 mm/min 1 30 mm (Standard Grip) 50 mm (Optional Grip) Pneumatic Specimen Clamp Air (outside of supply scope) 0.5 MPa~ 0.7 MPa 950 mm 450 mm (L) x 450 mm (W) x 1410 mm (H) AC 220V 50 Hz 70 kg Configurations Standard Mainframe, Professional Software, LCD Monitor, Keyboard, Mouse, Universal Grips Configurations and...

 Open the catalog to page 3
