Adhesion Test rolling Ball Method Laboratory Equipment

Adhesion Test rolling Ball Method Laboratory Equipment
1 / 1Pages

Catalog excerpts

Adhesion Test rolling Ball Method Laboratory Equipment - 1

PARAM® CZY-G Primary Adhesive Tester Professional Technology • Based on the rolling ball method and test the instant adhesive property of specimens • Testing steel balls are designed strictly according to national standards, which ensure the accuracy of test data • Angle of inclination could be adjusted freely to meet customer test requirements Test Principle The instrument is designed based on the balling method, and the primary adhesive property of adhesive tapes could be obtained by observing adhesive effect occurred immediately after rolling ball and adhesive specimen come into contact. This test instrument conforms to the standards: GB/T 4852, JIS Z0237 Applications CZY-G is professionally applicable to the determination of primary adhesive property of: Basic Including various adhesives, e.g. pressure-sensitive tapes, medical patches, Adhesives Applications adhesive labels and protection films Specifications Angle Range Panel Width Testable Area Width Standard Steel Ball Instrument Dimension Net Weight _CZY-G_ 0 ~ 60° 120 mm 80 mm 1/32 inch ~ 1 inch 320 mm (L) x 140 mm (W) x 180 mm (H) 6 kg Please Note: Labthink is always dedicated to the innovation and improvement of product performance and function. Therefore, technical specifications are subject to change without further notice. Please visit our website at www.labthink.com for the latest updates. Labthink reserves the rights of final interpretation and revision. Labthink Instruments Co., Ltd. 144 Wuyingshan Road, Jinan, P.R.China (250031) Phone: +86-531-85068566 FAX: +86-531-85062108 Labthink International, Inc. 200 River's Edge Drive, Medford, MA, 02155, U.S.A. Phone:+1-617-830-2190 FAX: +1-781-219-3638 www.labthink.com
