GreenLine
40Pages

= Wheels = Min. / max. temperature alarm = Graphic temperature recorder = Lock= Open door alarm= Power failure alarm = Internal light = Temperature programmer for thermal cycling WR 90 - 102 series thermostatic chambers / precision incubators refrigerated with water jacket W.80 - W.82 series precision water bathՕ W.82/O - W.84/O series precision water bath with linear and/or orbital shaking W180CCI.IR model CO2 Incubator series Օ WRS 96 - 85 series thermal refrigerating chambers with photoperiod control for environmental simulation Օ GreenLine Introduction WR UR700C model Climate Chamber...

While refrigerators and freezers (BluLine ) are meant to store perishable products, reactants,biological materials and medicine at a low or extremely low subambient temperature necessary for short and long term preservation and to control temperature in biochemical processes and analytical determinations, incubators (refrigerated and non-refrigerated thermostats) and thermostatic baths (GreenLine) are the primary instruments of any biological laboratory, be it for research, medical-clinical analysis, veterinary medicine, agri-food analysis, or quality and production control in the...

PID thermoregulation. KW incubators are currently provided with electronic PID (proportional, integral, derivative) thermoregulators, with LED digital indicator, for either heating and cooling, obtaining maximum stability and maximum safety against excessive fluctuations, overshoot, etc. and against accidental handling, making it impossible to modify PID parameters. These parameters therefore have a considerable impact on the quality of thermoregulation and have been optimized for each incubator model and memorized in EPROM. Thermal uniformity in incubators is guaranteed by bilateral...

Memorization of thermal cycles. When requested, in the more advanced models, W-LAB, WR-LAB, WRC, it is possible to memorizeseveral temperature-time pairs, for the creation of thermal cycles. The electronic instrumentation used is highly versatile with ramp/stasis function able to guarantee high performance. Designed to offer high control performance, these instruments represent the complete solution for a large variety of applications, such as the control of refrigerated incubators, climate and growth chambers, applications that require a precise control of heating/cooling and process...

Reliability and lifespan. AISI 304 (or AISI 316) stainless steel internal chamber, for W-LAB, WR-LAB series and for all water baths , in BA glossy finish. Same with the shelves , in perforated steel sheet, or steel wire. Internal chamber with rounded edges for easy cleaning and maximum hygiene. Double door for minimum heat dispersion and maximum stability of internal microclimate; in tempered glass for W-LAB, WR-LAB series, door with double/triple chamber round opening in glass for WPLR series, double door in transparent plastic for the other series. Internal lighting in all Prevention of...

Pivoting wheel kit (front wheels with brake) to facilitate incubator mobility 1 12 Closure system with ergonomic handle , with key closure Magnetic PVC gasket , on specific design, for maximum safety against thermal loss at the door and minimum energy consumption. 2 Insulation in glass mineral fibres, for maximum thermal protection and minimum energy consumption 13 Bilateral thermostatted air circulation, following a particular aeraulic course, created with a specific internal chamber architectureSupplemental probe for T, RTD Pt100, (optional) Single stage refrigeration system CFC HCFC free...

Model Externaldimensions (WxDxH) Internaldimensions (WxDxH) Capacity No. ofShelves Range ofadjustment % precisionon set value Power Weight WI 9WI 18 cm. 50x32x30 hcm. 53x35x35 h cm. 28x19x18 hcm. 31x26x23 h 10 litres 19 litres 22 (*) +70C(*) +70аC 2%ѱ 2% Watt. 200 Watt. 400 Kg. 17 Kg. 24 (*) +5C above ambient TPower supply 220/50/1 Volt > Model Externaldimensions (WxDxH) Internaldimensions (WxDxH) Capacity Shelves Range ofadjustment % precisionon set value Power Weight WI 30WI 60WI 100 WI 140 WI 200 cm. 65x52x52 hcm. 90x52x52 h cm. 71x68x86 hcm. 71x68x104 h cm. 71x68x136 h cm. 31x30x34 hcm....

WPL - WPLR > series INCUBATORS > air incubators INCUBATORS FOR BIOMEDICAL AND SCIENTIFIC LABORATORIES WITH DIGITAL ELECTRONIC HEATING AND REFRIGERATION CONTROL KW renews its decades of tradition in laboratory equipment, fit for the production of precision thermostatted environments, with the production of a new line : WPL WPLR . WPL stands for Warming Project in Laboratory and WPLR stands for Warming Project in Laboratory with Refrigeration. The project֒s objective is to provide a highly versatile and ergonomic line for scientific use, with low profiles and equipped with instrumentation of...

WPL > series INCUBATORS > table and floor incubators control panelinternal chamberinternal door lock internal door lock tempered glass internal doordoor seal 198 size="-2">

Model Externaldimensions (WxDxH) Internaldimensions (WxDxH) Volume(usable) Shelves HeatingSystem Power(installed) Weight WPL 50 WJWPL 80 AJWPL 200 WJ cm. 46x48x68 hcm. 62x63x75 hcm. 62x65x107 h cm. 34x34x43 hcm. 49x50x36 h cm. 50x50x80 h 50 litres80 litres200 litres n.3 n.2 n.4 WJ(*)AJ(+)WJ(*) W 300W 240 W 500 Kg. 40 Kg. 55 Kg. 90 (*) WJ= with water jacket(+) AJ= with air jacket T range: from +5հC above ambient temperature to +50C V230/1/50 power supply . T stability:<б 0.2 T uniformity:< 0.2 > KW APPARECCHI SCIENTIFICI

WPLR > series INCUBATORS > refrigerated table and floor incubators control panel lock with key internal chamber door hinge internal chamber 200 size="-2">

Model Externaldimensions (WxDxH) Internaldimensions (WxDxH) Volume(usable) Shelves PowerCooling Heating Consumptionmax KWh Weight WPL 100 RWPL 200 R WPL 300 R cm. 54x62x108 hcm. 54x62x172 h cm. 61x68x188 h cm. 45x44x51 hcm. 45x42x107 h cm. 52x48x122 h 100 litres200 litres 300 litres n.2 n.4 n.5 W 200 W 150W 260 W 200 W 300 W 280 0,2900,350 0,350 Kg. 60Kg. 100 Kg. 140 T range: from +5C to +50аCAmbient T Max +32C V230/1/50 power supply . T stability:<б 0.5 T uniformity < 0.5 > KW APPARECCHI SCIENTIFICI
