BloodLineRapid freezer for Plasma on contact / KW APPARt*. 5303S MONTERCCtOnl [61J ■ VIA BELLA RCSISTBy :i^rnj -qi. □' -_i cnn ^LSii;.r;i j ttnfcTiiili de Mpue'ill f-'O ^ Cwifl *IHen npkhi pli t-\ UvhKW iMJananzidi nd appvsli: dS (Jef»1p tnMos^ ri lufl thshWDfHiS ;■ appiOTajia™ * riaaOHad; Kw'tadir€lP*i&j“CiCEE INlMuifcmvo delntooS pA qu^ls vgara

Rapid freezer for Plasma on contact RAPIDITY FREEZING the bag is in contact with the surfaces of the wells and intense extraction of thermal energy is obtained in this manner, minimizing in this way the freezing time: < 45 ‘ for 24 (450 ml.) nominal standard bags, with a net content of plasma of at least 230 cc. and an initial temperature between + 25°C and + 30°C KW has undertaken tests with bags with a mass of 260 gr. each. Besides, in many experiences, made in hospital laboratories, with full charged freezer, were evaluated times of 55’ for 400 mL charge of plasma, 60’ for 600 mL charge...

Rapid freezer for Plasma on contact The expansion of the refrigerating fluids is obtained using special thermostatic valves; the evaporators made up of serpentine tube in cooper thermally connected – to the entire external peripheral surface of the freezing wells. The solution, together with the use of tanks for refrigeration, guarantees: • a great reserve of liquid, a consecutive fast response to the cold request in the act of introducing the bags and therefore a high refrigerant capacity (very rapid freezing) • high internal temperature uniformity. The entire thermofluidodynamic circuit...

Standard 450 ml. bags after freezing 1000 ml. bags After freezing Cooling curve in the freezing wheels Internal case of the rapid freezer with standard 450 ml. bags in freezing

Control panel for rapid freezing for plasma NEW SYSTEM SEMI-AUTOMATIC STORAGE KW Opened door, wells free for introduction and/ or extraction of plasma bags When the door is closed, the baffles automatically move, compressing plasma bags inside the wells, for the best freezing CONTROL PANEL AUTOMATIC DATA DOWNLOADING Possibility of automatic data downloading to the end of each cycle of freezing and availability/traceability of the plan of freezing on the internal laboratory network. At the same time of the refrigeration system action, time count on the digital electronic recorder is...

Model Max external dimensions Plasma bags Internal wells Used Power supply Weight (lxwxh) shelf level refrigerants KPFF 48B cm. 179x84x126 h 117 cm n.12 (to 4 bags cad.) R404A ed R508B V 400/3/Hz 50 +N+T max absorption 10 A

CONTACTS: Managing Director: management@kwkw.it Technical Production Manager: technician@kwkw.it Tender Commercial Office: customorservice@kwkw.it International Sales Manager: expdpt@kwkw.it Technical Support & Spare Parts: assistenza@kwkw.it Service line: service@kwkw.it Delivery Office: delivery@kwkw.it Administration: administration@kwkw.it KW Apparecchi Scientifici, taking into consideration the non change of the principal characteristics of products, has the right o carry out modifications on its products, without prior notice, that it deems necessary. This catalogue is on an informative...
