EA64-5
1Pages

Catalog excerpts

5Amp with Full Wave Auxiliary Winding or PMG Automatic Voltage Regulator PWM Output Compatible with ABB EA63-5Features • Voltage regulation less than +/-0.5% • 220/380/440Vac programmable input • Rugged compact design • Droop compensate • Analogue voltage input • With under frequency protection • Soft start voltage ramping • EMI suppression • Built-in high capacity 5Amp fuse Sensing Input Voltage 220/440 Vac 1 phase 190 to 290 Vac @ 220 Vac 330 to 515 Vac @ 440 Vac Frequency 50/60 Hz (SW1 selectable) Power Input (1 phase) Voltage 30 to 260 Vac 1 phase Frequency 40 to 500 Hz Excitation Output Voltage Max. 85 Vdc @ power input 110 Vac Max. 170 Vdc @ power input 220 Vac Current Continuous 5A Intermittent 10A for 60 seconds Resistance Greater than 9 ohms External Voltage Adjustment VR Max. +/-5% @ 1K ohm 0.5 watt potentiometer Max. +/-10% @ 2K ohms 0.5 watt potentiometer Volts Regulation Less than +/-0.5% (with 4% engine governing) Build Up Voltage 5Vac 25Hz residual volts at power input terminal Typical System Response Less than 1 Cycle Static Power Dissipation Max. 12 watts Quadrature Droop Input CT 5A or 1A > 5VA (SW2 selectable) Max. +/-7% @ PF +/-0.7 Analogue Voltage Input Un 0 to 15% @ 0 to 10 Vdc Under Frequency Protection (Factory Presets) 50/60 Hz (SW3 selectable) 40 to 50 Hz @ 50 Hz preset 45 Hz 49 to 60 Hz @ 60 Hz preset 55 Hz Voltage Thermal Drift Less than 3% at temperature range AVR Control Functions VOLT Voltage adjustment STAB Stability adjustment U/F Setting under frequency protection knee point Droop Droop adjustment TRIM Analogue input adjustment KUTAI ELECTRONICS INDUSTRY CO., LTD. TEL : +886-7-8121771 FAX : +886-7-8121775 Website : www.kutai.com.tw Headquarters : No.3, Ln. 201, Qianfu St., Qianzhen Dist., Kaohsiung City 80664, Taiwan

Open the catalog to page 1
