KUJ HC-220

KUJ HC-220

KUJ HC-220

Product catalog summary
Overview: The KUJ HC-220 is a high-capacity cutting machine designed for industrial food processing, capable of handling up to 8,000 kg per hour. It is suitable for cutting large quantities of vegetables, fruits, and other foods into cubes, strips, or slices with precise cutting quality.
Specifications:
  • Capacity: Up to 8,000 kg/h
  • Product Diameter: Up to 220 mm
  • Cutting Thickness: 2.5–25 mm, adjustable in 2.5 mm steps
  • Electrical Power: 4 kW, 400 V N/PE, 50 Hz (optional 60 Hz)
  • Dimensions: 1057 x 1525 x 1582 mm
  • Weight: 406 kg
Key Features:
  • High output with consistent cutting quality.
  • Adapted for large products, reducing pre-cutting needs.
  • Extensive cutting tools for various cut sizes.
  • Compact design for easy integration into processing lines.
  • Quick tool change for different products or cut sizes.
  • Safe and ergonomic operation with minimal product spillage.
Benefits:
  • Ideal for processing large quantities of vegetables, fruits, meat, and fish.
  • Reduces labor requirements due to high automation.
  • Ensures optimal hygiene with easy cleaning and maintenance.
  • Flexible operation with adjustable cutting speed and optional belt infeed/outfeed.
Applications: Suitable for industrial processing of various food products, including fruits, vegetables, fish, and meats like ham and bacon. It is particularly effective for producing fine cuts such as brunoise and larger cuts like potato cubes.
See more

Catalog excerpts

KUJ HC-220-1

KUJ HC-220 cube, strip & slice cutting machine High capacity of up to 8,000 kg per hour: for cutting large quantities of vegetables, fruit and other food into cubes, strips or slices. Even large products with a diameter of up to 220 mm are processed with the highest cutting quality.

 Open the catalog to page 1
KUJ HC-220-2

KUJ HC-220 cube, strip & slice cutting machine Your benefits Product groups Precise cutting quality for cubes, strips and slices – even very fine cuts possible High output with up to 8,000 kg/h with precise and consistent cutting quality Adapted for processing large products up to 220 mm in diameter Optimal hygiene, quick tool change and maximum safety Extensive cutting tools for cuts into slices, strips and cubes in 2.5 mm steps Compact high-performance machine with a low space requirement – as a stand-alone machine or for integration into a processing line Portrait Cut large quantities of up...

 Open the catalog to page 2
KUJ HC-220-3

KUJ HC-220 cube, strip & slice cutting machine many products. Its large funnel also allows ergonomic filling using boxes up to 600 mm wide. The large selection of cutting inserts enables the production of very thin slices and strips as well as ultra-fine cubes (brunoise) and at the same time also ensures optimal cutting quality for large cutting sizes. With selecting the cutting speed in seven steps you can adjust the machine to get the optimum cut quality for your product as product parameters might vary throughout the season. As a standard the machine is equipped with an interlock to use the...

 Open the catalog to page 3
KUJ HC-220-4

KUJ HC-220 cube, strip & slice cutting machine Simple cutting insert Simple and safe operation, The cutting inserts can be changed easily The easily accessible design of the machine using two stainless steel tools, which are allows for easy maintenance as well as optionally available. As a result, the machine thorough cleaning and therefore optimal can be converted in no time when the hygiene. Special emphasis was placed on product or cut size is changed. The safety during the product infeed and quick removal of the inserts also enables easy cleaning of the machine. Technical data Electrical...

 Open the catalog to page 4
