Designed specifically to measure the gloss of surfaces that cannot be measured using traditional glossmeters, the Novo-gloss flex 60 glossmeter combines the functionality and reporting of an advanced glossmeter with an ultra lightweight remote measuring head. The Novo-Gloss Flex 60 has been designed specifically to measure low gloss surfaces. It features an additional measuring scale with a resolution 10 times greater than standard glossmeters. This increased resolution gives a far superior level of control of surface finish. The Novo-Gloss Flex 60 complies to ISO 2813 and measurements made with...

Gloss is an aspect of the visual perception of objects that is as important as colour when considering the psychological impact of products on a consumer. it has been defined as "the attribute of surfaces that causes them to have shiny or lustrous, metallic appearance". The gloss of a surface can be greatly influenced by a number of factors, for example the smoothness achieved during polishing, the amount and type of coating applied or the quality of the substrate. Manufacturers design their products to have maximum appeal: highly reflective car body panels, gloss magazine covers or satin black...

Gloss is measured by shining a known amount of light at a surface and quantifying the reflectance. The angle of the light and the method by which the reflectance is measured are determined by surface and also aspect of the surface appearance to be measured. The unit of measurement for gloss is the Gloss Unit (GU) and the measurement scale at 60 degrees is 0-1000GU where 0 = a completely matt surface and 1000 = a perfect mirror. The Novo-Gloss Flex 60 has a measurement range of 0 -125 GU and can measure anything from matt surfaces to high gloss finishes typically seen in the automotive industry....

Fast measurement of all parameters. Full on-board statistics with graphical trend analysis and reporting. Simultaneous measurement of all parameters, results are date and time stamped. Displays full statistics for the number of readings in the current batch. Graphical reporting for quick trend analysis. Pass/ Fail parameters can be defined for instant identification of non-conformances. Memory: ON [100% free] Delete last measurement Start new batch Delete current batch Auto batch :0N Batch name :PART Easy batching User definable batch names and batch sizes for quicker and more efficient reporting....

Instrument calibration The Novo-Gloss Flex 60 is supplied with 2 calibration standards for low and high gloss which gives increased accuracy and resolution for low gloss surfaces. The calibration standards are magnetically enclosed which offers superior protection from contamination. The standards are magnetically attached to the instrument measuring head to ensure repeatible calibration. Measurement head The instrument is supplied with interchangeable measurement adaptors. 2. Steel surface adaptor (magnetic) for increased repeatibility for ferrous materials. Both adaptors can be replaced if...

Measuring angle 60°: universal angle for almost all gloss levels Measurement area GUh scale (improved resolution for low gloss) Measurement range Repeatability Other instrument specifications Colour screen Screen high resolution illuminated colour display: brightness adjustable Statistical analysis Graphical analysis Max, Min, Mean, S.D. On board trend analysis Rechargeable Lithium Ion; >17 Hours operation; >14,000 Readings/Charge Data memory 8 MB >999 Readings; user definable batching Data transfer Bluetooth"; PC & MAC®compatible; USB Connection Dimensions & weight Included accessories • Certified...
