Product catalog summary

Illuminance Meter T-10 Series Overview: The T-10 Series measures illuminance levels from 0.01 to 299,900 lux or 0.001 to 29,990 foot-candles. Models include the T-10 with a standard receptor, T-10M with a mini receptor for small spaces, and T-10WS/T-10WL for underwater and outdoor use.

Specifications: Features a silicon photocell with a spectral response within 8% of the CIE standard. Offers auto-ranging and measures various illuminance metrics. Powered by AA batteries with RS-232C digital output for PC connectivity.

Applications: Suitable for lighting engineering, R&D, quality control, and maintenance in industries like construction, agriculture, and forestry.

Features: Includes quick zero adjustment, multi-point measurement, LCD back-lighting, and auto-ranging. Measures flickering light sources with digital and analog outputs.

Advanced Functions: Supports reference value setting, color correction, and various illuminance metrics. Optional PC software for enhanced data processing.

Accessories: Comes with a receptor cap, neck strap, and case. Optional accessories include multi-point adapters and data processing software.

Konica Minolta Luminance Meters LS-100 and LS-110 Specifications: Compact SLR luminance meters with narrow acceptance angles (1° for LS-100, 1/3° for LS-110). Wide measuring range from 0.001 to 299,900 cd/m² (LS-100) and 0.01 to 999,900 cd/m² (LS-110).

Measurement Accuracy: Accuracy within ±2% ±2 digits for lower values and ±2% ±1 digit for higher values. Repeatability within ±0.2% ±2 digits for lower values and ±0.2% ±1 digit for higher values.

Calibration and Correction: Supports user calibration and color correction with a factor range of 0.001 to 9.999.

Display and Communication: 4-digit LCD with LED backlight. RS-232C interface for data communication.

Power and Consumption: Powered by a 9V battery, consuming 16mA when measuring and 6mA when idle.

Operating Conditions: Operates between 0 to 40°C with up to 85% humidity. Storage from -20 to 55°C.

Optional Accessories: Includes close-up lenses, long eye-relief eyepiece, and angle finder VN. Data Printer DP-10 for additional functionality.

UV Radiometer UM-10 Overview: Measures ultraviolet radiation with interchangeable receptor heads covering 220-480nm. Suitable for semiconductor manufacturing, biological applications, and sterilization.

Chroma Meter CL-200 Overview: Measures tristimulus values, chromaticity, color temperature, and illuminance. Suitable for R&D and color inspection in lamp manufacturing and display calibration.

Chroma Meter CS-100A Overview: Compact, battery-powered for non-contact luminance and chromaticity measurements. Features a 1° measurement angle and supports absolute and difference measurement modes.

Conclusion: The document highlights the precision and versatility of these instruments for industrial and scientific applications, supported by optional accessories and software enhancements.
