Using unique features of Digital Konsensus Pro, color image formation is precisely controlled on special color paper while maintaining a high quality reproduction of halftone. Various print conditions such as dot density, trapping density and color tone can now be faithfully reproduced. As a result, DCP becomes a truly invaluable asset for your digital printing. Base colors simulating various stock papers can be reproduced. ● Variable control of dot density ● Colorcontrol-CC (Optional Software) > Precise control of dot density, which was not previously possible, allows for color tones that...

Open the catalog to page 2

By using the Output Device Link System, you are able to achieve a color proof system that can be interfaced to various pre-press systems, realizing true CTP workflow. By selecting various print sizes (A1/B2/A2/A3) from three different sizes of roll paper, you are able to significantly reduce the paper- waste of each print. ǉى TIFF CMYK މى 1bit TIFF > ɹɾ TIFF IT/P1 > Output Device Link System Loading two types of paper in the Digital Konsensus Pro enables efficient print production by automatically selecting paper size that is appropriate for the image size. ɹɾ Handshake ɹɾ Export PS ɹɾ...

Open the catalog to page 3

C Humidity : 40 60%RHExposure Unit :1,080(W) x 1,465(D) x 1,200(H) mmProcessing Unit : 910(W) x 1,160(D) x 965(H) mmVacuum Unit : 470(W) x 650(D) x 660(H) mm Exposure Unit : 700 kgProcessing Unit : 150kg Vacuum Unit : 70kgAC 220 ~ 240V > System ConfigurationExposure Method Imaging Type Max. Paper SizeMax. Exposure SizeMax. Output Speed Output Resolution Rolls to be set Front SystemOperating ConditionExternal DimensionsTotal WeightPower Supply Exposure Unit/Processing Unit/Vacuum UnitOuter Drum Digital Halftone 670mm x 970mm A1 wide(660mm x 960mm) 15pages(A1 wide)/hr2,400dpi2...
