AKD BASIC

Product catalog summary

Overview: The AKD BASIC Servo Drive by Kollmorgen is a versatile two-in-one device combining a servo drive with programmable control, eliminating the need for an external PLC in many applications. It allows for direct motion and machine control on each axis, enhancing efficiency and reducing dependency on higher-level control systems.

Key Features:

Fast commissioning with Auto-Tuning.
Intuitive programming using the Basic language, which is easy to learn.
User-friendly development environment with Kollmorgen WorkBench, which includes program download and upload capabilities.
Program password protection to safeguard intellectual property.
Extensive I/O options with 20 digital inputs, 13 digital outputs, and 2 analog inputs and outputs, with I/O expansion available.
Program storage and parameter set uploads to an SD card, eliminating the need for a PC during commissioning.

Benefits:

Customized functions can be implemented quickly.
Reduced hardware requirements and lower installation costs.
Implementation without modifying existing machine control systems.

Development Tools: The Kollmorgen WorkBench provides a comprehensive user interface for programming, configuration, and optimization. It includes features such as predefined command libraries, auto-complete functionality, color-coding for code differentiation, and a debugger with breakpoints and step commands.

I/O Interface Configurations:

AKD BASIC Standard Unit: 8 digital inputs, 3 digital outputs, 1 analog input, 1 analog output.
AKD BASIC with I/O Expansion: 20 digital inputs, 13 digital outputs, 2 analog inputs, 2 analog outputs.

Disclaimer: Specifications are subject to change without notice, and it is the user's responsibility to determine the product's suitability for specific applications.

Catalog excerpts

Two-in-One: Servo Drive with Programmable Control AKD BASIC - Programmable servo drive may be used in many applications without an external PLC ffCustomized functions implemented quickly ffLess hardware, lower installation costs ffImplementation without modifying the machine control ffSimple, easy to learn programming in Basic With AKD BASIC – High Flexibility for each Axis • Fast commissioning with Auto-Tuning • asy to learn, intuitive programming in Basic E • ser-friendly development environment, Workbench, program download and U upload in one tool! • rogram password protection - protects your intellectual property P • 0 digital inputs and 13 digital outputs with I/O expansion 2 • analog inputs and outputs, I / O expansion 2 • rogram storage and parameter sets upload to SD card, no PC required for P commissioning With AKD BASIC you can realize motion and machine control directly on each axis without an external PLC. Users can work independently of the development team to optimize the drive and fulfill customer requirements quickly, safely and without the need for higher-level control systems. This shortens the testing phase and protects you from surprises during commissioning. The Basic programming language is easy and fast to learn - in just a short time you will develop individual programs for machine interfacing and motion control functions. The Kollmorgen WorkBench assists you with powerful development tools including the program editor with syntax checking, program templates, extensive testing and debugging tools.

Open the catalog to page 1

Because Motion Matters™ Maximum Productivity with the Kollmorgen WorkBench The powerful Kollmorgen WorkBench provides a complete user interface for programming, configuration and optimization, with drive management, motion and machine control interfacing functions. The Kollmorgen WorkBench development environment for AKD BASIC provides all the tools for software development, testing and debugging. ‘♦J Step Into (F8) (^1 Step Over (F10) 4J Step Out (Shift+FII) $ Toggle Breakpoint (F9) ^ Delete All Breakpoints ^ Enable All Breakpoints Disable All Breakpoints ie Move.RelativeDist ise Move.RelativeDist se...

Open the catalog to page 2
