INTALOX Commercialized in the 1970s,structured packings of corru-gated sheet metal were developed and introduced to themarket by Koch-Glitsch. FLEXIPAC > Ү Structured Packinghas been the industry standard since that time. INTALOX > Structured Packing,introduced in 1986,demonstrated an increased capacity over other availablestructured packings.The most recent development, FLEXIPAC > ή HC > Structured Packing,was introduced in1997.In addition to its high capacity,FLEXIPAC HC packingoffers a lower pressure drop when operating near its maxi- mum capacity.Each type of structured packing has a specific...

Introduced in 1986,INTALOX structured packing was shown to have greater "efficient capacity" than other struc- tured packings.A patented,aggressively textured surface, combined with patented corrugation reversals in each packing layer,along with other subtle proprietary geometric features, give INTALOX structured packing a higher capacity.Combining excellent performance characteristics with aunique "efficient capacity" rating correlation,INTALOX structured packing has been successfully utilized in a varietyof high liquid rate,high pressure systems besides the usualapplications in vacuum and atmospheric...

FLEXIPAC Since its introduction in 1997,FLEXIPAC HC structuredpacking has been used in hundreds of columns to increase capacity and reduce pressure drop both in new construction and for replacing standard sheet metal structured packings,conventional random packings and trays.Combining excellent capacity and efficiency char- acteristics along with a lower pressure drop per theo- retical stage,it is the preferred packing for use in vacu- um distillation applications.FLEXIPAC HC is similar in construction to standardFLEXIPAC packing,except for a subtle modification in the geometry of the corrugation...

System:o-/p-XylenesDiameter:8 in [203 mm] Packing Depth:10 ft [3.05m] Total Reflux Operation 720 mm Hg mm inches 20 mm Hg HETP, HETP, 300 mm Hg 5 mm Hg System:o-/p-XylenesDiameter:8 in [203 mm] Packing Depth:6 ft [1.83 m] Total Reflux Operation mm mm inches inches 720 mm Hg 20 mm Hg5 mm Hg HETP, 300 mm Hg HETP, HETP, HETP, System:CB/EBTotal Reflux Operation Pressure:40 mmHg DX ծ inches mm
