Overview

This document provides detailed technical specifications and data for various housings designed for LED lamps. It includes part numbers, materials, optical properties, dimensions, and viewing angles for multiple LED housing models.

1. Specifications of LED Lamp Housings

The document lists numerous LED housing models identified by part numbers (e.g., DI4/GE0252MK, V5-DI4/GE0252MK, DY4/GE0252MK, etc.). Each model is characterized by:

• Material: Various materials such as PaG, PsAaG, and sAlAaG are used.
• Wavelength (λ): Specified in nanometers, typically around 526 nm (red), 885 nm (yellow), 865 nm (green), and others.
• Luminous Intensity (Iv): Given in candela (cd), values vary per model and color.
• Viewing Angle: Defined by minimum and typical 2θ angles, commonly 40°, 60°, or 30°.
• Dimensions: Provided in millimeters (with inches in parentheses), with tolerances of ±0.25 mm (0.01 inches).

2. Optical and Mechanical Parameters

Each housing model includes detailed optical parameters such as lens type and luminous intensity for different LED colors (red, yellow, green, white). Mechanical dimensions include length, width, and height, often with notes on right-angle or level positioning.

3. Notes and General Guidelines

• All dimensions are in millimeters (inches).
• Tolerance for dimensions is ±0.25 mm (0.01 inches) unless otherwise specified.
• Parts with different internal resistors for 6V, 12V, and 24V are available; users should consult sales offices for availability.

4. Housing for LED Lamps

The document also lists housing part codes (e.g., 05-BC, 25-CTR, 13-CTR, 03-BC, etc.) without detailed specifications but indicates similar dimensional and tolerance notes.

5. Summary of Key Parameters

6. Critical Recommendations

• Verify the correct part number and corresponding optical/mechanical specifications before ordering.
• Confirm voltage and internal resistor specifications with sales offices to ensure compatibility.
• Adhere to dimensional tolerances for proper fit and performance.

Conclusion

This technical document serves as a comprehensive reference for selecting and specifying LED lamp housings with precise optical and mechanical characteristics. It is essential for engineers and procurement specialists involved in LED lighting design and manufacturing.
