Overview

This technical document provides comprehensive specifications for various numeric and alphanumeric LED displays, including single to multi-digit numeric displays, dot matrix displays, and detailed package dimensions with internal circuit diagrams. All measurements are standardized in millimeters (with inches in parentheses) and maintain a tolerance of ±0.25 mm (0.01") unless otherwise noted.

1. Single Digit Numeric Displays

This section details single digit numeric displays identified by part numbers such as 30XS, 63XS, 93XS, and others. Key parameters include package types and materials (e.g., gray face, white segment), wavelength in nanometers, forward voltage at 10mA, common anode or cathode configurations, and precise dimensional data. Face sizes range approximately from 0.25 inch (6.31 mm) to 0.93 inch (23.6 mm).

2. Single & Dual Digit Numeric Displays

Displays with one or two digits are described here, including models like AWE11-32AS and AWRS11-32AS. Parameters mirror those of single digit displays, covering package description, material, wavelength, voltage, and dimensions. Face sizes typically range from 0.42 inch (10.65 mm) to 0.93 inch (23.6 mm).

3. Dual, Three & Four Digit Numeric Displays

This section covers multi-digit numeric displays (two to four digits) such as AWE15-65AD and AWRS15-65AD. Specifications include package type and material, wavelength, voltage at 10mA, common anode or cathode configuration, and dimensions. Face sizes generally start around 0.65 inch (16.5 mm) and larger.

4. Four Digit Numeric & Alphanumeric Displays

Four-digit numeric and alphanumeric displays like AWE14-40AC and AWRS14-40AC are detailed here. Features include face sizes from approximately 0.4 inch (10.1 mm) to 0.65 inch (16.5 mm), material and segment color (gray face, white segment), wavelength, voltage data, and common anode or cathode configurations.

5. Alphanumeric Displays & Dot Matrix

This section describes alphanumeric and dot matrix displays, including part numbers such as AWE11-32ASP and AWRS11-32ASP. Important parameters include matrix sizes (e.g., 7x5, 8x8), face and segment colors, wavelength, voltage at 10mA, and package dimensions. Dot matrix displays are specified with detailed matrix dimensions and typical application notes.

6. Package Dimensions & Internal Circuit Diagrams

Extensive data on package dimensions and internal circuit diagrams are provided for series such as KCSA/KCSC02, KCDA/KCDC03, and others. Each series includes dimensional drawings in millimeters and inches, with tolerances of ±0.25 mm (0.01"), along with notes on package types and series numbering conventions.

Critical Information and Best Practices

• All dimensions must be considered with the stated tolerance of ±0.25 mm (0.01") to ensure proper fit and function.
• Material and face color selection impact display visibility and should align with application requirements.
• Wavelength and forward voltage data are essential for electrical compatibility and brightness optimization.
• Common anode or cathode configurations must match the driving circuitry to ensure correct operation.
• Package dimensions and internal circuit diagrams are critical for accurate PCB layout and integration.

Additional Series and Model Listings

The document also enumerates multiple component series such as SA/SC10, DA/DC03, BA/BC04, CA/CC04, PSA/PSC, PDA/PDC54, TA/TC, and TBA/TBC, listing specific model numbers within each. Consistent notes emphasize measurement units (millimeters with inches) and a standard tolerance of ±0.25 mm (0.01") across all series.

Summary

This document serves as a detailed reference for engineers and designers selecting and integrating numeric and alphanumeric LED displays. It provides standardized mechanical and electrical specifications, ensuring compatibility, performance, and quality control in design and manufacturing processes. The uniform application of measurement units and tolerances facilitates precise interpretation and implementation across various component series and models.
