Catalog excerpts
Optoelectronic Components
Open the catalog to page 1
HIGH BRIGHTNESS PLCC LEDs water clear water clear water clear water clear POLARITY MARK Units : mm(inch) water clear POLARITY MARK water clear Units : mm(inch) water clear water clear water clear POLARITY MARK water clear water clear water clear Units : mm(inch)
Open the catalog to page 2
HIGH BRIGHTNESS LED 8 PART NUMBER MATERIAL lD (nm) LENS TYPE IF (mA) Pd (W) Öv (lm) VIEWING ANGLE DIMENSION TYP. TYP. 2q1/2 KASL-4805ZGSX15/3 InGaN 525 water clear 350 4.55 35 120° 48mm x 5mm x 1.6mm KASL-4805QBFSX15/3 InGaN 465 water clear 350 4.2 25 120° KASL-4805SEL1SX15/5 AlGaInP 618 water clear 500 4.6 100 120° KASL-4805SYL1SX15/5 AlGaInP 590 water clear 500 4.95 100 120° KASL-4805ZG25SX15/7 InGaN 525 water clear 700 8.12 260 120° KASL-4805QB25SX15/7 InGaN 450 water clear 700 8.12 53 120° HIGH BRIGHTNESS LED LIGHT BAR Units : mm(inch) Tolerance : ±0.25(0.01) PART NUMBER MATERIAL lD...
