K-TEK-M275TP-FN-BL-FC-ML

Product catalog summary

Product Overview: The K-TEK-M275TP-FN-BL-FC-ML is a rugged military keyboard featuring 91 keys, including 12 function keys and a sealed touchpad. It is designed for durability and precision, with a silicone rubber front plate and stainless steel back plate. The keyboard is fully sealed to IP67 standards, making it resistant to harsh environments.

Specifications: The keyboard uses carbon contact and FPC carbon-on-gold key switch technology, offering a key travel of 1.50mm±0.10mm and an actuation force of 1.2N±0.2N. It supports over 5 million operations and includes an adjustable white backlight. The dimensions are 283.0mm x 177.7mm, and it weighs 248g.

Electrical Data: The keyboard operates on a DC +5V±5% supply voltage, with a current rating of ≤30mA without backlight and ≤300mA with backlight. It is compatible with various operating systems, including Windows, Linux, Unix, Mac OSX, Vxworks, and Android.

Environmental Adaptability: The keyboard is designed to operate in temperatures ranging from -40℃ to +75℃ and can be stored between -50℃ and +80℃. It has undergone extensive testing for humidity, vibration, shock, temperature shock, fungus, salt spray, rain, and dust resistance.

Reliability and Certifications: The keyboard is RoHS compliant, CE and FCC certified, and meets MIL-STD-810H standards for environmental adaptability. It has a key lifespan of over 5 million actuations, an MTBF of over 20,000 hours, and an MTTR of less than 30 minutes.

Applications: This keyboard is suitable for use in vehicles, aerospace, naval, defense, maritime, radar, consoles, portable rugged laptops, and UAV ground stations.

Catalog excerpts

MODEL NO.: K-TEK-M275TP-FN-BL-FC-ML DESCRIPTION: 91 keys IP67 fully sealed and durable embedded ultra thin silicone rubber rugged military keyboard, with sealed & ruggedized tough touchpad for fast and accurate cursor position, with built-in ultra-thin Flexible Printed Circuit and semi-reinforced ultra-thin stainless steel back plate, 12 function keys(F1, F2, ... F12) are on top line for easy operation, with combination numbers on letter keys for full keyboard functionality. The keyboard adopts silicone rubber front plate + PC keycaps and carbon contact + FPC carbon-on-gold key switch technology, with 1.50mm±0.10mm key travel with extremely good tactile feeling for fast and accurate data input without any noise, there will be no key value missing, no stuck key during the keyboard operation, with durable coating & anti-microbial keyboard surface withstand most chemicals and liquids under harsh environment. FN + Clean combination keys for easy cleaning without taking the keyboard away from PC to avoid mis-operation or mis-typing. Adjustable white backlight included, top panel mount solution.Designed to meet MIL-STD-810H (high and low wide working temperature, low pressure, humidity, vibration, shock, salt spray, temperature shock, drop, rain, sand and dust, fungus, solar radiation etc.),and MIL-STD-461G-EMC-EMI-EMS-ESD (optional), as well as the critical military standards in these 10 aspects: reliability, safety, maintainability, testability, supportability, environmental adaptability, stability, compatibility, consistency, and continuity. Dimensions: 283.0mm x 177.7mm (Front panel)

Open the catalog to page 1

MECHANICAL DATA

Open the catalog to page 2

) Key Technology Rugged System Ltd Head Office: B702, Building 1, Tianan Cyber Park, No. 524, Qinglin Road, Huanggekeng Community, Longcheng Subdistrict, Long Gang District, Shenzhen, Guangdong, P.R.China Factory ADD.: Floor 7, Building S8, Fenggang Tianan Cyber Park, No. 208 Fenggang Section, Dongshen Road, Fenggang Town, Dongguan, Guangdong, P.R.China Website: www.rugged-system.com,www.rugged-key.com E-mail: [email protected], [email protected]

Open the catalog to page 3
