K-TEK-M270-FN-BL-ML-DWP

Product catalog summary

Product Overview: The K-TEK-M270-FN-BL-ML-DWP is an 86-key ruggedized military keyboard designed for extreme environments. It features an IP65 dynamic waterproof and vandal-proof aluminum alloy construction with durable polymer keys. The keyboard includes 12 function keys and a sealed PCB with carbon-on-gold key switch technology for enhanced tactile feedback.

Mechanical Specifications: The keyboard is constructed with a high-quality aluminum alloy panel processed by CNC. Key sizes vary, with normal keys measuring 14.0mm x 14.0mm, the enter key at 14.0mm x 28.0mm, and the space bar at 14.0mm x 70.0mm. The key travel is 1.20mm, and the actuation force ranges from 1.0N to 1.5N. The switch life exceeds 5 million operations.

Electrical Specifications: The keyboard operates on a DC +5V±5% supply voltage, with a current rating of 30mA without backlight and 300mA with backlight. It complies with EMC standards EN 55032:2015 and EN 55035:2017 and has a lifespan of over 5 years. Interfaces available include PS2 and USB, compatible with various operating systems.

Environmental Adaptability: The keyboard operates in temperatures ranging from -40℃ to +75℃ and can be stored between -45℃ and +85℃. It withstands saline mist for 96 hours and damp heat at +40℃ for 21 days, as per IEC 60512-6 standards.

Reliability and Standards: The product is RoHS compliant and meets CE, FCC, and ESD standards. It is designed to MIL-STD-810H and MIL-STD-461G standards, ensuring reliability in harsh conditions. The protection level is IP65, and it is vandal resistant to IK09 standards.

Applications: Suitable for use in vehicles, aerospace, naval, defense, maritime, radar, consoles, portable rugged laptops, and UAV ground stations.

Catalog excerpts

MODEL NO.: K-TEK-M270-FN-BL-ML-DWP DESCRIPTION: 86 keys IP65 dynamic waterproof vandal proof aluminum alloy ruggedized military keyboard with durable polymer keys. The high quality ruggedized aluminum alloy panel is processed by CNC. With 12 function keys(F1, F2, ... F12) on the top line of keyboard. Sealed and ruggedized PCB with carbon-on-gold key switch technology with stroke 1.20mm, which is extremely good tactile feeling for fast and accurate data input without any noise. one complete silicone rubber along the top panel for easy mounting & sealing tightly with cabinet, Rear panel with countersunk hole for easy mounting. Adjustable white backlight included . FN + Clean combination keys for easy cleaning without taking the keyboard away from PC to avoid mis-operation or mistyping. The whole keyboard can meet wide temperature(Operating temperature: -40℃ to +75℃). High quality durable black titanium spray-paint on the aluminum alloy panel, which is good for outdoor application with direct rain and very harsh environments with humidity, much dynamic water, oil, salt mist etc. USB cable with cable length 1.5M. Designed to meet MIL-STD-810H (high and low wide working temperature, low pressure, humidity, vibration, shock, salt spray, temperature shock, drop, rain, sand and dust, fungus, solar radiation etc.),and MIL-STD-461G-EMC-EMI-EMS-ESD (optional), as well as the critical military standards in these 10 aspects: reliability, safety, maintainability, testability, supportability, environmental adaptability, stability, compatibility, consistency, and continuity. DIMENSIONS: 270.0mm(L) x 110.0mm(W) (Top Panel

Open the catalog to page 1

Key Technology Rugged System Ltd Head Office: B702, Building 1, Tianan Cyber Park, No. 524, Qinglin Road, Huanggekeng Community, Longcheng Subdistrict, Long Gang District, Shenzhen, Guangdong, P.R.China Factory ADD,: Floor 7, Building S8, Fenggang Tianan Cyber Park, No. 208 Fenggang Section, Dongshen Road, Fenggang Town, Dongguan, Guangdong, P.R.China Website: www.rugged-system.com,www.rugged-key.com E-mail: [email protected], [email protected]
