K-TEK-D343TP-FN

Product catalog summary

Specifications:
Model: K-TEK-D343TP-FN
Dimensions: 343.0mm x 125.0mm
Description: 81-key compact format IP65 dynamic rated membrane industrial keyboard with function keys, sealed touchpad, and gold-on-gold key switch technology. Features FN+CLEAN key for easy cleaning.
Mounting: Top panel mounted with optional aluminum or stainless steel back plate.
Colors: White, Black
Weight: 1.30KGs
Key Dimensions: 14.0mm x 14.0mm
Touchpad: Sealed, ruggedized, capacitive with 10 million strokes lifespan.
Power Supply: 5VDC ± 0.25V
Current Rating: <10 mA
Interface: PS2, USB
OS Compatibility: Windows, Linux, Unix, Mac OSX, Vxworks, Android.

Applications:
Ideal for environments such as manufacturing, material handling, medical settings, military, industrial automation, pharmaceutical, oil and gas, food and beverage, and more.

Main Features:
Rugged, compact design with full-size versatility. Protected against dust, dirt, grease, and corrosive liquids. Customizable with multiple languages. FN+Clean key allows cleaning without data transmission.

Mechanical Data:
Key Switch Technology: Metal dome PCB with short stroke keys.
Actuation Force: 3.5N±0.2N
Key Travel: 0.45mm
Key Switch Lifetime: 1 million operations
Touchpad Resolution: 40 Counts/mm
Tracking Speed: Max 1,016 m/sec

Electrical Data:
Supply Voltage: DC +5V±5%
Current Rating: 50mA
EMC Standard: EN 55032:2015, EN 55035:2017
Lifespan: >5 years

Environmental Adaptability:
Operating Temperature: -20℃ to +65℃
Storage Temperature: -30℃ to +75℃
Operating RH: 100%
Protection Level: IP65 dynamic

Reliability:
RoHS, CE, FCC certified
Key Lifespan: >1 million actuations
MTBF: >20000H
MTTR: <30min

Catalog excerpts

Key Technology Rugged System Ltd Head Office Add: B702, Building 1, Tianan Cyber Park, Huang Ge North Rd, Longcheng Subdistrict, Long Gang District, ShenZhen, Guang Dong Province, P.R. China. Factory Add: Floor 7, Building S8, Fenggang Tianan Cyber Park, No. 208 Fenggang Section, Dongshen Road, Fenggang Town, DongGuan, Guang Dong Province, P.R. China. E-mail: [email protected], [email protected] Website: www.rugged-system.com,www.rugged-key.com Model NO.: K-TEK-D343TP-FN DIMENSIONS: 343.0mm x 125.0mm (top panel) DESCRIPTION: 81 keys compact format IP65 dynamic rated membrane industrial keyboard with function keys on the upper line, with sealed and ruggedized tough touchpad for fast and accurate cursor position, industrial metal dome PCB with gold-on-gold key switch technology with short stroke 0.45mm with extremely good tactile feeling for reliable data input, with FN+CLEAN key for easy cleaning via lock/disable the entire keyboard without needing to take away the keyboard from PC, surface mounted extremely flush with anti-microbial, durable and scratch-proof polyester withstand to most chemicals and liquids under the harshest environments, ruggedized aluminum or stainless steel back plate optional, with threaded bolts for top panel mounted solution.
