Key Technology China Limited
Mechanical Keyboard with trackball K-TEK-M506-50-MTB-AVR-KP-FN-MA-BL-151B-BT-DT

Mechanical Keyboard with trackball K-TEK-M506-50-MTB-AVR-KP-FN-MA-BL-151B-BT-DT

Product catalog summary

Product Overview: The K-TEK-M506-50-MTB-AVR-KP-FN-MA-BL-151B-BT-DT is a rugged, waterproof military-grade mechanical keyboard featuring 107 keys, including a numeric keypad and 12 function keys. It includes a 50mm removable anti-vibration trackball with 400DPI resolution and three mouse buttons. The keyboard is housed in a stainless steel black titanium electroplated casing, designed for standalone desktop use.

Specifications: The keyboard is IP54 rated for water resistance and built to withstand harsh environments. It features a mechanical axis key switch with a 4.00mm key travel and an actuation force of 0.55N. The device operates on a DC +5V supply voltage and has a current rating of 30mA without backlight and 300mA with backlight.

Standards and Compliance: The keyboard meets several military standards, including MIL-STD-461G for EMC, EMI, EMS, and ESD, MIL-STD-901D for shock resistance, and MIL-STD-810H for environmental adaptability. It is also RoHS compliant and CE and FCC certified.

Environmental Adaptability: The keyboard operates in temperatures ranging from -40℃ to +75℃ and can be stored in temperatures from -45℃ to +85℃. It withstands saline mist for 96 hours and damp heat at +40℃ for 21 days.

Reliability: The keyboard has a lifespan of over 40 million key actuations, an MTBF of over 20,000 hours, and an MTTR of less than 30 minutes.

Applications: This keyboard is suitable for use in vehicles, aerospace, naval, defense, maritime, radar systems, consoles, portable rugged laptops, and UAV ground stations.

Catalog excerpts

Mechanical Keyboard with trackball K-TEK-M506-50-MTB-AVR-KP-FN-MA-BL-151B-BT-DT-1

Model NO: K-TEK-M506-50-MTB-AVR-KP-FN-MA-BL-151B-BT-DT DESCRIPTION: 107 keys IP54 rated waterproof rugged durable embedded military mechanical keyboard, with built-in wide temperature military grade PCB, with numeric keypad, 12 FN keys (F1, F2...F11, F12) are on top line for easy operation, as well as 50mm removable and anti-vibration black or red hardened resin mechanical ball module with 400DPI resolutions for fast and accurate cursor position, 3 mouse buttons on top of the trackball. Rugged stainless steel black titanium electroplated housting for movable standalone desktop solution, PC material button, with mechanical axis key switch and 4.00mm long stroke with extremely good tactile feeling for fast and accurate data input, with durable coating & antimicrobial surface to withstand bacteria and work well under harsh environment, with green backlight included and USB interface. Designed to meet MIL-STD-461G (EMC, EMI, EMS, ESD), MIL-STD-901D and MIL-STD-810H (high and low wide temperature, low pressure, humidity, vibration, shock, salt spray, temperature shock, drop, rain, sand & dust, fungus, solar radiation etc.), which can also meet the critical military standards in these 10 aspects: reliability, safety, maintainability, testability, supportability, environmental adaptability, stability, compatibility, consistency, and continuity. DIMENSION: 506.0*159.0*42.0mm (L x W x H)

Open the catalog to page 1

Mechanical Keyboard with trackball K-TEK-M506-50-MTB-AVR-KP-FN-MA-BL-151B-BT-DT-2

KEY TECHNOLOGY CHINA LIMITED Head Office: B702, Building 1, Tianan Cyber Park, No. 524, Qinglin Road, Huanggekeng Community, Longcheng Subdistrict, Long Gang District, Shenzhen, Guangdong, P.R.China Factory ADD.: Floor 7, Building S8, Fenggang Tianan Cyber Park, No. 208 Fenggang Section, Dongshen Road, Fenggang Town, Dongguan, Guangdong, P.R.China Website: www.rugged-system.com,www.rugged-key.com E-mail: [email protected], [email protected]

Open the catalog to page 2

Mechanical Keyboard with trackball K-TEK-M506-50-MTB-AVR-KP-FN-MA-BL-151B-BT-DT-3

Open the catalog to page 3
