K-TEK-M379-OTB-KP-FN-BL-DT-FM data sheet

Product catalog summary

Product Description: The K-TEK-M379-OTB-KP-FN-BL-DT-FM is a ruggedized industrial keyboard featuring 121 keys, including an integrated numeric keypad and 24 function keys. It is designed with an IP68 dynamic sealed silicone rubber construction, making it resistant to harsh environments. The keyboard includes a 25.0mm optical trackball with 800 DPI resolution for precise cursor control.

Main Features: The keyboard is equipped with red adjustable backlighting, suitable for use with night vision goggles in aviation or vehicle applications. It is fully sealed to protect against dust, dirt, and liquids, ensuring durability in industrial settings. The keyboard supports multiple languages and connects via PS/2 or USB.

Mechanical Data: The keyboard features protuberant rectangular keys with a tactile feel, a key travel of 1.50±0.10mm, and an actuation force of 1.5N±0.2N. It is designed to withstand over 5 million operations and includes a 25.0mm diameter trackball.

Electrical Data: Operating at a supply voltage of DC +5V±5%, the keyboard has a current rating of 50mA without backlight and 300mA with backlight. It complies with EMC standards EN 55032:2015 and EN 55035:2017.

Environmental Adaptability: The keyboard operates in temperatures ranging from -20℃ to +65℃ and can be stored between -30℃ and +75℃. It is tested for saline mist, damp heat, and dry heat, withstanding 100% humidity and atmospheric pressures of 60-106Kpa.

Reliability: The product is RoHS compliant, CE and FCC certified, with an IP68 protection level. It has a key lifespan of over 5 million actuations, an MTBF of over 20,000 hours, and an MTTR of less than 30 minutes.

Applications: Suitable for use in vehicles, aerospace, naval, defense, maritime, radar, consoles, portable rugged laptops, and UAV ground stations.

Catalog excerpts

K-TEK-M379-OTB-KP-FN-BL-DT-FM data sheet-1

Model NO: K-TEK-M379-OTB-KP-FN-BL-DT-FM DESCRIPTION: 121 keys IP68 dynamic sealed & ruggedized silicone rubber industrial keyboard, integrated numeric keypad, 24 function keys (F1, F2...F11, F12...F23, F24) on the top line for easy operation, IP68 dynamic rated 25.0mm optical trackball module with 800 DPI resolutions for fast and accurate cursor position with extremely smooth operation,industrial PCB with carbon-on-gold key switch technology with long stroke (1.50mm±0.10mm) with extremely good tactile feeling for fast and accurate data input without any noise, with durable coating & antimicrobial keyboard surface treatment withstand to most chemicals and liquids under harsh environment, FN+ CLEAN combination key for easy cleaning via locking/disable the entire keyboard without needing to take away the keyboard from PC, top panel mountable desk top version with IP68 dynamic sealed stainless steel metal housing with brused surface treatment, with stainless steel mounting plate on both sides for panel mounting optional, adjustable industrial backlight included. Military level optional. DIMENSIONS: 400.8mm x 196.4mm x 31.0mm (L x W x H)

Open the catalog to page 1

K-TEK-M379-OTB-KP-FN-BL-DT-FM data sheet-2

MAIN FEATURES: Keyboard has red adjustable backlighting, while backlighting makes this keyboard ideal for aviation or vehicle applications where night vision goggles are necessary. The trackball pointing device is a completely sealed 25.0mm optical unit, featuring a removable ball for convenient cleaning. The trackball is operated using sealed rubber switch with 3 mouse buttons designed for right & left clicking and scrolling up and down with ball rolling. Keyboard provides full-size versatility in a rugged, compact design, rugged construction for reliable functionality The keyboard lacks the...

Open the catalog to page 2

K-TEK-M379-OTB-KP-FN-BL-DT-FM data sheet-3

Damp heat test at +40℃ Atmospheric pressure RELIABILITY RoHS compliant, CE and FCC certified Protection Level Vehicle, aerospace, naval, defense, maritime, Radar, console, portable rugged laptop, UAV ground station etc
