K-TEK-B80KP-40-IT-DWP datasheet
K-TEK-B80KP-40-IT-DWP datasheet
- Durable stainless steel design resistant to vandalism and corrosion.
- IP65 waterproof rating with easy mounting options.
- Excellent tactile feedback with short travel switches.
- Laser-etched key legends for durability and readability.
- Customizable for multiple languages.
- Available with various interfaces: PS2, USB, RS232, RS485.
- Supply Voltage: DC +5V±5%
- Current Rating: 30mA
- EMC Standards: EN 55032:2015, EN 55035:2017
- Lifespan: > 5 years
- Compatible OS: Windows, Linux, Unix, Mac OSX, Vxworks, Android
- Front and Back Plate: 1.5mm brushed stainless steel
- Key Size: 10.0mm x 10.0mm
- Key Travel: 0.45mm±0.05mm
- Actuation Force: 2.5N±0.2N
- Switch Life: >1 million operations
- Weight: 0.80KGs
- Operating Temperature: -20℃ to +65℃
- Storage Temperature: -30℃ to +75℃
- Operating RH: 30-90%
- Atmospheric Pressure: 60-106Kpa
- Saline Mist: 96 hours, IEC 60512-6
- Damp Heat Test: +40℃ for 21 days, IEC 60512-6
- Dry Heat Test: +85℃ for 10 days, IEC 60512-6
- RoHS Compliant, CE and FCC certified
- ESD Protection Level: IP65
- Vandal Resistance: IK09
- Key Lifespan: >1 million actuations
- MTBF: >20000H
- MTTR: <30min
Catalog excerpts
MODEL NO.: K-TEK-B80KP-40-IT-DWP DESCRIPTION: 40 keys compact format IP65 dynamic water proof and vandal proof Stainless Steel industrial keypad with industrial metal dome PCB electronics controller shielded & protected by stainless steel housing, industrial metal dome PCB with gold-on-gold key switch technology with short stroke 0.45mm with excellent tactile feeling for stable and accurate data input, rear stainless steel plate with mounting holes and sealing gasket for easy tightly rear panel mounting. Which is good for outdoor application with direct rain and very harsh environments with humidity, much dynamic water, oil, dirt, salt mist etc. DIMENSIONS: 140.0mm x 80.0mm (front panel)
Open the catalog to page 1
APPLICATION This Keyboard is mainly targeted for use for unsupervised or semi-supervised positions of varied access applications, internet terminals and information kiosks at universities, shopping malls, hotels, banks, airports, railway-stations and other public areas, ticket vending machines, gas stations, cash machines (ATMs/CDM), Internet public phones etc. MAIN FEATURE ● Imposing stainless steel design, specially designed keyboards meet the highest demands with regard to design, functionality, longevity and high protection level. ● Stainless steel fascia and key-tops guard willful destruction,...
Open the catalog to page 2
Operating Temperature Storage Temperature Atmospheric Pressure Saline Mist Damp heat test at +40℃ RELIABILITY RoHS Compliant, CE and FCC, ESD Protection Level IP65 dynamic (front panel) Vandal Resistant Industrial, coal and mine, medical, bank kiosk and self service terminal, public access, explosion-proof automation, oil and
