K-TEK-B111-50-MTB-BT datasheet
1 / 2 PagesView full catalog
K-TEK-B111-50-MTB-BT datasheet
Product catalog summary
Product Overview: The K-TEK-B111-50-MTB-BT is a ruggedized stainless steel trackball designed for industrial use. It features a 50.0mm hardened resin mechanical ball module with IP65 static waterproof and dustproof protection. The device includes three short-travel metal mouse buttons, with the middle button offering a scrolling function. The front panel is made of high-quality durable black titanium-plated stainless steel, suitable for embedded installation.
Technical Specifications:
- Mechanical Parameters: The device includes three convex circular buttons with a travel distance of 0.45mm. The trackball diameter is 50mm, with an expected lifespan of over 10 million rotations. The buttons have a lifespan of over 1 million presses and require a pressure of 3.2N±0.1N. The front panel dimensions are 106.8mm x 171.8mm, and it is mounted on a 3.0mm aluminum plate.
- Interface: Available with PS2 and USB interfaces, including a Y-type cable option.
- Electrical Parameters: Operates on a 5V DC±5% power supply. The power consumption is ≤1.00W during operation and ≤0.2W when idle. The device meets IP65 protection standards for the front panel and complies with EN 55032:2015 and EN 55035:2017 electromagnetic compatibility standards.
- Environmental Conditions: The operating temperature range is -40ºC to +80ºC, with a storage temperature range of -45ºC to +85ºC. It can operate in relative humidity levels of 30-90% and atmospheric pressure of 60-106Kpa.
- Reliability: The device is RoHS, CE, and FCC certified, with ESD protection. It has a mean time between failures of over 20,000 hours and a mean repair time of less than 30 minutes.
- System Compatibility: Compatible with all Windows, Linux, Unix, Mac OSX, Vxworks, and Android systems, with U-cos testing pending.
- Packaging: Each unit is packaged in an appropriate inner box, which is then placed in a standard outer box.
See more
Catalog excerpts
产品型号: K-TEK-B111-50-MTB-BT 产品尺寸: 106.8 x 171.8 x 45 mm (前面板) 产品描述: IP65 静态防水防尘防暴的加固型不锈钢轨迹球带 IP65 静态防水的 50.0mm 直径的硬化树脂机
Open the catalog to page 1
PS2, USB 两种接口, 可提供带 USB 和 PS2 两种都带的 Y 型接线
Open the catalog to page 2All Key Technology China Limited catalogs and technical brochures
