Flexible custom sawing solutions ■ Circular saws for steel and aluminium ● Circular saw for aluminium TL - SKL - RKL ■ Band saws for steel and aluminium Systems for steel construction/service centers ■ Circular/band sawing machines ■ Drilling machines for steel sections ■ Plate processing centres ■ Coping robot ■ Punching/shearing lines >

TL 250 TL 350TL 450Quick acting clam-ping device, mova- ble in three planes. Clamping block of hardwood for clam- ping on both sides of the saw blade > Workpiece guide movable for mitre cuts from 30 left to 45а right. Arresting by clamp lever. To increase the cutting capacity the workpiece guide can be set to the back by 40 mm (TL 350) respectively 60 mm (TL 450) and is inde- xable by pin on 2 different angle scales > Cutting range for various demands >

SKL 450 E/H Features of SKL series:Excellent cut quality by steplessly adjustable blade feed and clam- ping of the workpiece on both sides of the blade Horizontal and vertical clamps with adjustable clamping pressure for optimum material clamping KALTENBACH principle of upstroking blade, ensuring excel- lent swarf management Large cutting capacity due to ad- justable workpiece stop and rotating table with a mitre range of 180 > SKL 450 ESKL 450 H with length mesuring systen L 40 NC and T3 transport system Workpice clamping at both sides of the saw blade, presetting of material width and heightPneumatic...

UNIVERSAL CIRCULAR SAWING MACHINES SKL 450 E, H, NA | 4 5 SKL 450 NA SKL 450 NA Based on the renowned SKL 450 H the highly automated SKL 450 NA presents an efficieny high perfor- mance sawing maching with robust infeed system:Automatic material feed for cut-ting lengths up to 9,999 mmSpecially designed feed gripper for minimum end pieces Special clamping jaw options for complex profiles Optionally fully automatic flat maga- zine for pre-storage of material Technical data see page 7 Short cycle times due to electro- mechanical material feed Optimum swarf removal by chip conveyor and/or chip extraction...

Based upon the heavy duty construction the RKL 551 AX pre- sents a high performance sawing machine particularly suited for cut- ting the various shapes of alumini- um and aluminium alloys.The well-designed machine with its proven technology offers significant benefits:Excellent cut quality due to work-piece clamping on both sides of the blade and infinitely variable sawblade feedEasy operation with graphic dis-play and ergonomic arrangement of all control elementsNon-contact recognition of bar end by light barrierRest piece length 80 mm Optimium surface finish due to automatic in-cycle blade...

THE KALTENBACH RANGE Semi-/fully automatic circular sawing machines for metal and non-ferrous materialsSemi-/fully automatic bandsawing machines for solid material, profi les and structural sections Structural drilling machines Circular saw for structural sectionsCoping robots Kaltenbach 2008 ɢ֠ Kaltenbach reserves the right to alter specifi cations without further notice ■ Printed in Germany 01/2008 Punching/Shearing linesPlate processing centres Kaltenbach GmbH + Co. KG Postfach 17 40 ■ D-79507 LrrachTel.: +49 (0) 7621 / 175-0Fax: +49 (0) 7621 / 175-477 [email protected] >
