Fexible Aluminium Sawing Solutions TL – SKL – RKL

RKL 551 AX The high performance sawing machine RKL 551 AX is the fi rst choice for the cutting of rectangular and precise cut-offs from aluminium profi les of various shapes as well as solid materials and aluminium alloys. Flexible aluminium sawing solutions The right saw for each application Large range for various sawing purposes in aluminium and aluminium alloys KALTENBACH offers a wide program in circular saws whether manually operated or in semi- or fully automatic version. All machines of TL, SKL or RKL series meet the specifi c demands of sawing aluminium and its alloys in an optimal manner....

TL 350 TL 250 TL 450 TL 350 TL 450 Flexible aluminium sawing solutions For Use on Site or in Workshops TL Serie Cutting range TL Transport of 250 for on site use Working range TL 250 TL 350 TL 450 Sawblade Ø mm 250 350 450 Drive capacity kW 1,1 2,0 2,2 Cuttingspeed m/min 2.700 3.200 4.100 90°/45° mm 75/75 110/110 145/145 90°/45° mm 65/65 100/90 130/120 90°/45° mm 100 x 60 / 80 x 60 160 x 80 / 140 x 60 200 x 100 / 160 x 80 Mitre cutting range 30° – 90° – 30° . Acurate and safe operation with upstroking saw blade . Easy adjustment for mitre cuts . Pneumatic clamping by foot-pedal (option at TL...

SKL 450 H Flexible aluminium sawing solutions-profile Semi- and fully automatic sawing machines SKL 450 Serie SKL 450 E/H Features of SKL series: . Excellent cut quality by steplessly adjustable blade feed and clamping of the workpiece on both sides of the blade . Horizontal and vertical clamps with adjustable clamping pressure for optimum material clamping . KALTENBACH principle of upstroking blade, ensuring excellent swarf management . Large cutting capacity due to adjustable workpiece stop and rotating table with a mitre range of 180° . Easy operation by ergonomic arrangement of all control...

SKL 450 NA SKL 450 NA Based on the renowned SKL 450 H the highly automated SKL 450 NA presents an efficieny high performance sawing maching with robust infeed system: . Automatic material feed for cutting lengths up to 9,999 mm . Specially designed feed gripper for minimum end pieces . Short cycle times due to electromechanical material feed . Optimum swarf removal by chip conveyor and/or chip extraction system . NC option with serial interface for bar-orientated sawing . Efficient atomised coolant lubricant system enhances blade life . Preset gripper and clamping jaws to accommodate a wide range...

neues Bild neues Bild Flexible aluminium sawing solutions-profile High performance sawing machine for rectangular cuts in Aluminium RKL 551 A Workpiece clamping with torsion-free, pneumatic vertical clamp on left side of the saw blade, pneumatic cut-off clamp, with short stroke clamping cylinder each Feed carriage with electro-mechanic feed via brushless servo-motor and ball screw spindle . . Based upon the heavy duty construction the RKL 551 AX presents a high performance sawing machine particularly suited for cutting the various shapes of aluminium and aluminium alloys. The well-designed machine...

¡ Standard Option – not possible Technische Daten SKL 450 E SKL 450 H SKL 450 NA RKL 551 AX Sawblade Ø mm 450 450 450 550 Drive capacity - Standard - optional kW 3,7/4,7 3,7/4,7 4,7/6,3 3,7/4,7 4,7/6,3 6,0 Cutting speed m/min 1.950/3.900 1.950/3.900 1.950/3.900 5.000 Saw blade feed, - infi nitely variable - Rapide return stroke mm/min mm/min 0 - 3.000 4.500 0 - 3.000 4.500 0 - 3.000 4.500 0 - 2.600 3.500 Material feed - single stroke - multiple stroke max. mm 10 - 1.000 9.999 10 - 1.000 9.999 Weight kg 680 680 1.480 2.850 Dimensions - Length - Width - Height mm 1.275 1.720 2.000 1.275 1.720 2.000...

Robotic Coping Machines Band- and Circular- Sawing Machines Drilling Machines Transport Systems Contour Marking Punching/Shearing Machines Plate Processing Centers Kaltenbach GmbH + Co. KG Postfach 17 40 D-79507 Lörrach Blasiring 4 D-79539 Lörrach Tel.: +49 (0) 7621 / 175-0 Fax: +49 (0) 7621 / 175-477 [email protected] www.kaltenbach.com KALTENBACH Metall Working Systems: The Full Range. In addition to an standard extensive programm KALTENBACH offers special solutions for metal working. Ask for our brochure as well as any additional information you might require.
