Kalamazoo Industries, Inc.

Product catalog summary

Overview: The document outlines the specifications and features of abrasive cut-off saws by Kalamazoo Industries, Inc., designed for various industrial cutting needs.

Model Specifications:

Model K8B: 8" saw, 3 HP motor, 4900 RPM, single/three-phase options.
Model K10B: 10" saw, 3 HP motor, 3450 RPM, swivel vise, optional floor stand and chain vise.
Model K7B: 7" saw, 1 HP motor, 4800 RPM, handles 1" rounds and 2" pipes.
Model K14SS: Heavy-duty, 5 HP motor, 4400 RPM, quick-lock swivel vise.
Model K12-14V: Uses 12"/14" wheels, 5 HP motor, 4400 RPM.
Model K20SW: 20" saw, 15 HP motor, 1950 RPM, manual cam vise.
Model K26S: 26" saw, 20 HP motor, 1800 RPM, cam vise.
Model KM14: 14" saw for non-ferrous materials, 5 HP motor, 4400 RPM.

Key Features:

Customizable motor phases and voltages.
Optional features: power down feed, oscillation, air vise, stock conveyors.
Safety features: magnetic switches, sealed bearings, OSHA-compliant guards.
Durable construction with cast iron bases and trunnions.

Applications: Suitable for cutting solid rounds, pipes, and non-ferrous metals in industrial settings.

Vibratory Finisher Model S-346 Specifications:

Capacity: 3.3 cubic feet, 500 lbs.
Features: Quiet, portable, easy loading/unloading, rugged steel tub.
Power: 110 VAC.

Accessories:

KW-1 Spindle Wrench: For 1" arbor saws, 12"-26" saws.
AV-18/AV-20/AV-26 Air Vise: Fits 10"-26" saws, requires 0-100 PSI air.
KC5 Gravity Feed Conveyor: 1.9" rollers, 3000 lbs capacity per 5' section.

Indexing Equipment:

Universal-Indexer: For drill presses, milling machines, grinders.
6" Index Table: 6" chuck, 24 indexing ring.
5C Index Fixture: For drilling, milling, grinding.
Collet Holding Fixture: For 5C collets.
Air-Operated 5C Collet Holder: Versatile and accurate.

Abrasive Products:

Abrasive Sanding Belts: Various sizes and grits, dry and wet options.
Abrasive Sanding Discs: Sizes 10", 12", 20".
Abrasive Wheels: Non-reinforced and reinforced options.

General Information:

All products made in the USA.
Contact: Kalamazoo Industries, Inc., Phone: 269-382-2050, Fax: 269-382-0790, Website: www.kalamazooindustries.com

Catalog excerpts

Handles 1" solid round, 2" pipe. Օ Adjustable work length stop and down stop furnished. 1/2" wheel arbor. Օ Dimensions - L 22" x W 10" x H 14" More capacity, cuts 1-1/2" solid, 2" pipe.Օ 1/2" wheel arbor. Spark deflectors, front and rear, standard. Օ Dimensions - L 22" x W 10" x H 14". MODEL K7B 7" abrasive cut-off saw. 1 HP TEFC motor, 1 PH (110/220V). Please specify voltage. With cord and switch. Less abrasive wheel. 75 lbs. Spindle RPM - 4800. MODEL K8B 8" abrasive cut-off saw. 3 HP TEFC motor, 1 PH (110/220V) or 3 PH (220/440V). Please specify voltage. With switch; less abrasive wheel. 90...

Open the catalog to page 2

ABRASIVE SANDING BELTS > SIZE50 GRIT80 GRIT100 GRIT 1 x 42 DRY BELTSKB14250KB14280KB1421002 x 48 DRY BELTSKB24850KB24880KB248100 2 x 60 DRY BELTSKB26050KB26080KB260100 2 x 72 DRY BELTSKB27250KB27280KB272100 3 x 90 DRY BELTSKB39050KB39080KB390100 4 x 36 DRY BELTSKB43650KB43680KB436100 4 x 60 DRY BELTSKB46050KB46080KB460100 4 x 60 WET BELTSKWB46050KWB46080KWB460100 4 x 90 DRY BELTSKB49050KB49080KB4901006 x 48 DRY BELTSKB64850KB64880KB6481006 x 48 WET BELTSKWB64850KWB64880KWB648100 6 x 60 DRY BELTSKB66050KB66080KB660100 6 x 60 WET BELTSKWB66050KWB66080KWB660100 6 x 90 DRY BELTSKB69050KB69080KB690100...

Open the catalog to page 24
