Municipal vehicles
30Pages

{{requestButtons}}

Catalog excerpts

Municipal vehicles - 1

Sewer cleaning and disposal vehicles

Open the catalog to page 1
Municipal vehicles - 2

Economically efficient sewer cleaning Vehicles with water recycling Special vehicles Vehicles for arctic climates

Open the catalog to page 2
Municipal vehicles - 3

What do customers appreciate most about KAISER vehicles? Technology and quality KAISER vehicles impress with innovative technology and outstanding workmanship, making them a match for the toughest tests offered by rugged continuous operation. Flexibility and economic efficiency They are considerably more flexible and economical in terms of cost/benefit comparisons than the vehicles of other suppliers.

Open the catalog to page 3
Municipal vehicles - 4

Economically efficient sewer cleaning Jetting – Vacuuming – Water recycling Jetting A high-pressure water hose with a sewer jetting nozzle is fed into the soiled sewer. The high-pressure water jet dislodges the dirt and flushes it to the gully hole. At the same time, the water jet pushes the hose further into the sewer. Vacuuming The material flushed into the gully hole is extracted by means of a vacuum system. Solids and water are thus conveyed by the suction hose into the sludge tank. Combined sewer cleaning If jetting and vacuuming work can be performed simultaneously, we talk of a combi...

Open the catalog to page 4
Municipal vehicles - 5

Economically efficient sewer cleaning What does it mean to have 4 plants and a network of 45 sales and service partners across 5 continents? Customer proximity and regional support! Kaiser. Performance counts. KAISER technology – powerful and reliable In the sewer cleaning and waste disposal trade the name KAISER is synonymous with innovative technical solutions. As a vehicle manufacturer and system supplier, KAISER is worldwide leader in the sewer cleaning with water recycling sector. Economically efficient sewer cleaning

Open the catalog to page 5
Municipal vehicles - 6

KAISER pressure converter - KDU High-pressure water pump Function The pressure transformer principle developed by KAISER has proved its worth for over 30 years as the perfect solution for cleaning sewers, especially when combined with water recycling. The KDU is a hydraulically driven high-pressure water pump that directly converts oil pressure into water pressure. Pressure and flow rate can be set independently of one another. Technical data KDU high-pressure pump Max. delivery rate (USgal/min) Outstanding level of efficiency Using the truck auxiliary output drive, the KDU is driven via a...

Open the catalog to page 6
Municipal vehicles - 7

KAISER water ring pump - KWP Vacuum pump Technical data KWP Vacuum pump 900i 1600i 2400i 2000i 3100i Max. air flow in m3/h 900 Max. air flow in cfm 530 Max. vacuum rate in % 90 (in Hg) (26.6) Function As early as the mid-1980s, KAISER developed the first water ring pump in a light construction for mobile applications. In the KWP housing, an eccentric rotor produces a ring of water using centrifugal power. Volume changes in the rotor chambers ensure that air is sucked in and compressed. This construction type features high resistance to dirt particles and is ideally suited to vacuuming wet...

Open the catalog to page 7
Municipal vehicles - 8

KAISER Rotomax Water recycling system Patented KAISER system The centrepiece of the ROTOMAX water recycling system is an oscillating rotary filter drum. Built into the front part of the sludge tank, this one-stage filter system separates solids from sewer water. The filtered water is channelled directly (without settling basin) to the KAISER pressure transformer for further jetting processes. Outstanding efficiency Runs to refill with jetting water are dispensed with, fuel and water consumption reduced. A multi-stage filter system is not needed if the KDU is used. This reduces body weight...

Open the catalog to page 8
Municipal vehicles - 9

Hydraulic slew drive Backwash-flushing system Drum screen Oscillating rotary What can you expect from KAISER’s patented water recycling system? A saving of over 24,000,000 litres of water a year per vehicle. Kaiser. Performance counts. The benefits of KAISER technology for the customer: Superior economy and performance Outstanding efficiency. Automatic adjustment of the required power. Lower fuel consumption. Substantial reduction in the number of trips required for refilling and disposal. Significantly higher payload. High on reliability, low on emissions Insensitive to contaminated water....

Open the catalog to page 9
Municipal vehicles - 10

Why can you find KAISER vehicles in operation on 5 continents, in 114 countries and well over 1000 cities? Our vehicles cannot fail to impress with their innovative technology and outstanding workmanship. 2013 will mark 100 years of experience for KAISER. Kaiser. Performance counts.

Open the catalog to page 10
Municipal vehicles - 11

Vehicles with water recycling KAISER Aquastar Top performance for versatile deployment and flexible applications Efficient performance The KAISER Aquastar offers a perfect combination of performance and versatility. The KDU high-pressure pump delivers water at a rate of 320 to 500 litres per minute (with a double KDU up to 800 litres) and water pressure of up to 200 bar. The large-size hose reel can accommodate a 300 m jetting hose. On the KAISER vacuum pump the maximum air throughput is 3100 m3/h (with a double KWP up to 6200 m3/h). Due to the selection of various suction booms, the...

Open the catalog to page 11
Municipal vehicles - 13

Vehicles with water recycling KAISER Eco 3.0 Reliable in the toughest conditions Benchmark for water recycling The Eco 3.0 stands for the latest generation of the EcoCombi series which set new standards in the area of efficient sewer cleaning with water recycling. Very compact dimensions thanks to an extremely short wheelbase, modern design and the combined hose boom are the most striking new features along with the proven high-power components KDU, KWP and ROTOMAX. This vehicle has a maximum jetting capacity of 400 litres a minute and a maximum water pressure of 200 bar. The vacuum pump...

Open the catalog to page 13
Municipal vehicles - 14

Vehicles with water recycling KAISER compact vehicles 15–18 tons Equipped with proven KAISER components Continuous water recycling in compact dimensions The CityCycler is the smallest sewer cleaning vehicle with continuous water recycling, built on a 2-axle chassis with a gross vehicle weight of 15-18 tons. The vehicle’s compact dimensions give it maximum mobility in tight spaces. The jetting and suction hose boom at the rear of the vehicle reduces the space required at the job site. With the integrated fresh water tank, jetting operations can also be performed with clean water. Proven,...

Open the catalog to page 14
