VMC850 Vertical Machining Center

Product catalog summary
Specifications:
  • Table Size: 545 x 1000 mm
  • Axis Travel: X: 850 mm, Y: 560 mm, Z: 635 mm
Spindle Head:
  • Spindle Taper: BT-40 (CAT40)
  • Pull Stud: MAS-BT-40/P40-T
  • Spindle Speed: Gear: 4000 rpm (optional 6000, 8000 rpm), Belt: 8000 rpm (optional 10000 rpm)
  • Speed Variation: Infinitely variable (2 steps)
Feed:
  • Rapid Travel (X, Y, Z): 15000, 15000, 12000 mm/min
  • Feed Rate (X, Y, Z): 4000 mm/min
Automatic Tool Changer:
  • Standard: Yes
  • Magazine Capacity: 24 tools
  • Tool Selection: Random
  • Tool Change Type: CAM Type
  • Max Tool Diameter: 75 mm
  • Max Tool Length: 300 mm
  • Max Tool Weight: 6 kg
Motors:
  • Feed Motors: AC 2.1/2.1/2.1 KW (AC 2.5/2.5/2.5 HP)
  • Spindle Motor (Continuous/30 min): AC 5.5/7.5 KW (AC 7.5/10 HP)
  • Spindle Head Coolant: AC 0.2 KW ~ 4p (AC 1/4 HP ~ 4p)
  • Automatic Slideway: AC 25 W ~ 4p (1/20 HP ~ 4p)
  • Coolant Pump: AC 0.4 KW ~ 4p (AC 1/2 HP ~ 4p)
Additional Information:
  • Net Weight: 5500 kg
  • Specifications are subject to change without notice.
See more

Catalog excerpts

VMC850 Vertical Machining Center-1

CNC MACHININGCENTER Item VMC-850 Table size overall 545*1000mm X.Y.Z axis travel 850,560,635mm SPINDLE HEAD SPINDLE TAPER BT-40(CAT40) PULL stud MAS-BT-40/P40-T Spindle speed gear belt 4000rpm(*6000,8000rpm) 8000rpm(*10000rpm) Change of speeds Infintely variable(2 STEPS) FEED Rapid Travel (X.Y.Z) 15000,15000,12000mm/min Feed rate (X.Y.Z) 4000mm/min AUTOMATIC TOOL CHANGER Standard Magazine capaclty 24 Tool Selection Random Tool change type CAM Type Max. tool dia 䦘 75mm Max. tool length 300mm Max. tool Weight 6kgs MOTORS Feed motors AC2. 1/2. 1/2. 1KW(AC2.5/2.5/2.5HP) Spindle motor (Cont/30min) AC5.5/7.5KW (AC7.5/10HP) Spindle Head Coolant AC0.2KW~4p(AC1/4HP~4p) Automatic slideway AC25W~4p(1/20HP~4p) Coolant pump AC0.4KW~4p(AC1/2HP~4p) Net weight 5500kgs >
