VMC1050C Vertical Machining Center
1 / 1 PageView full catalog
VMC1050C Vertical Machining Center
Product catalog summary
Specification Overview:
- Model: VMC-1050C
- Axis Travel: X: 1050 mm, Y: 520 mm, Z: 520 mm
- Table Size: 1150 x 520 mm
- T-slot Dimensions: 18 x 5 x 100 mm
- Table Load Capacity: 500 kg
- Spindle Nose to Table Distance: 100-620 mm
- Spindle Center to Column Surface: 620 mm
- Spindle Taper: BT-40 / HSK-63A
- Spindle Speed: 8000 rpm (optional 15000 rpm)
- Rapid Traverse Speed: X, Y, Z: 24/32 m/min
- Cutting Speed: 10 m/min
- Magazine Capacity: 24 tools
- Tool Change Type: Arm type
- Max Tool Diameter: 75 mm
- Max Tool Length: 300 mm
- Max Tool Weight: 6 kg
- Spindle Motor Power: Continuous: 5.5 kW, 30 min: 7.5 kW (optional 18.5 kW)
- Motor Power: X Axis: 2.1/2.8 kW, Y Axis: 2.1/2.8 kW, Z Axis: 3.8/4.4 kW
Notes: Specifications are subject to change without notice. Optional features are available for spindle speed and motor power.
See more
Catalog excerpts
CNC MACHININGCENTER Specification: Item VMC-1050C X .Y. Z axis travel 1050,520,520 mm Table size overall 1150x520mm T-slot 18x5x100mm Table load capacity 500kgs Spindle nose to table 100-620 mm Spindle center to column surface 620mm Spindle taper BT-40 / HSK-63A Spindle speed 8000 rpm(*15000 rpm) Rapid traverse of X axis 24/32* m/min Rapid traverse of Y axis 24/32* m/min Rapid traverse of Z axis 24/32* m/min Cutting speed 10 m/min Magazine capacity 24 Tool change type Arm type Max. tool dia. 75mm Max. tool length 300 mm Max. tool weight 6 kgs Spindle motor (cont./30 min) AC 5.5/7.5(18.5)KW Motor of X axis AC 2.1 / 2.8KW Motor of Y axis AC 2.1 / 2.8KW Motor of Z axis AC 3.8/ 4.4 KW >
