Compressors - iSeries

Product catalog summary

Overview: The iSeries compressors by JUN-AIR are fully automatic, oil-less compressors designed for immediate use without installation. They are suitable for various applications and emphasize performance, design, and usability.

Key Features:

Flexible design with manual drain.
Oil-free air ensuring continuous operation and easy maintenance.
Supplied with a 2-year warranty.
Constructed with fewer moving parts for reduced wear and increased reliability.
Internally powder-coated receivers to prevent corrosion and maintain air quality.

Environmental Considerations: JUN-AIR products prioritize low energy consumption, minimal maintenance, and environmental concern.

Performance Specifications:

Models: i40-4B, i40-5B, i80-5B.
Voltage: 220-240 V, Frequency: 50 Hz.
Motor Power: 0.33 HP for i40 models, 0.67 HP for i80 model.
Displacement: 90 l/min for i40 models, 180 l/min for i80 model.
Free Air Delivery (FAD) at 7 bar: 28 l/min for i40 models, 56 l/min for i80 model.
Maximum Pressure: 7 bar (100 psi).
Noise Level: 66 dB(A) for i40 models, 68 dB(A) for i80 model.

Physical Specifications:

Tank Size: 4 liters for i40-4B, 25 liters for i40-5B and i80-5B.
Weight: 16 kg for i40-4B, 24 kg for i40-5B, 33 kg for i80-5B.
Dimensions: i40-4B - 351 x 327 x 286 mm; i40-5B and i80-5B - 622 x 336 x 536 mm.

Contact Information:

USA: JUN-AIR USA Inc., Benton Harbor, MI. Phone: +1 269/934-1216.
Europe: GAST GROUP Ltd, Redditch, UK. Phone: +44 (0)1527 50 4040.

Catalog excerpts

oil-less compressors The JUN-AIR i Series is the logical choice when an efficient but economical oil-less compressor is required. These compressors represent the complete compressed-air package, with a rocking piston compressor and air receiver. The series deliver a sturdy and compact design. The compressors have been constructed with fewer moving parts in order to reduce wear and provide maximum reliability and minimum maintenance. ,, The fully automatic compressors are ready to go right out of the box. They can be placed directly in the area where air is required and they are ideally suited...

Open the catalog to page 2

Europe GAST GROUP Ltd Unit 11, The I O Centre Nash Road Redditch, B98 7AS United Kingdom Phone: Telefax: E-mail: Internet: +44 (0)1527 50 4040 +44 (0)1527 52 5262 [email protected] www.gastmfg.com www.jun-air.com USA JUN-AIR USA Inc. 2300 Highway M-139 Benton Harbor MI 49022 USA +1 269/934-1216 +1 269/927-5725 [email protected] www.jun-air.com 6191802 - v.02-2000 - 08.2009 Phone: Telefax: E-mail: Internet:
