Precision Motion Specialist Stand Alone Stepper Electronics [ OPEN LOOP type / CLOSED LOOP type ] Integrated Stepper Electronics [ OPEN LOOP type / CLOSED LOOP type ] BLDC • VCM Motor Speed Control Electronics Jiangsu DINGS1 Intelligent Control Technology Co., Ltd. BLDC Motor Driver Input Vbltag* : 24 - 48 VDC Output Current: 6 A SUPPLY VOLTAQE HIGH 1 QR ♦ 3 RO SUPPLY VOLTAQI LOW \ QR ♦ 4 RP OTHER FAILURE 1 QR * S RP

Stand Alone Stepper Electronic OPEN LOOP TYPE │ Pulse input type of Open Loop 2-Phase Step Motor Drive Microstep resolution can be set through DIP switch setting Output current can be set through DIP switch setting Smooth filtering, Soft-Start function implementation Protection alarm output POWER SUPPLY OUTPUT RATED CURRENT (max) Step & Direction (1 pulse) or CW / CCW (2 pulse) INTERFACE INPUT / OUTPUT SIGNAL SIZE WEIGHT Pulse input type of Open Loop 5-Phase Step Motor Drive Microstep resolution can be set through DIP switch setting Output current can be set through DIP switch setting Protection...

Stand Alone Stepper Electronic CLOSED LOOP TYPE RS-485 communication type of Closed Loop 2-Phase Step Motor Drive Supporting up to 30 axes connection control through MODBUS-RTU protocol communication Various parameters can be set through DINGS’ Tuner Pro GUI DS-CLS10-FRS4-1A - Supporting ABS Encoder (Biss-C Type, Single-16bit / Multi-16bit) DS-CLS9-FRS4-01 - Dedicated drive with Force Control Function Command mode selectable - PULSE / RS-485 communication [ Force Control ] POWER SUPPLY 2 differential inputs 5 digital inputs 4 digital outputs 3 encoder signal inputs (differential) 3 encoder signal...

Stand Alone Stepper Electronic CLOSED LOOP TYPE │ Supports up to 2-axis control Support EtherCAT communication protocol, support control mode PP, PV, HM, CSP, CSV Motor short circuit protection, under-voltage protection, over-voltage protection, over-current protection, etc. Supports ABS encoder (BiSS-C type, 16-bit / 16-bit multi-turn) Exquisite design, low noise and low vibration Optically isolated inputs [ I=INC Encoder ] [ A=ABS Encoder / Biss-C type ] POWER SUPPLY OUTPUT RATED CURRENT (max) 4 digital inputs x 2 2 digital outputs x 2 1 brake output x 2 INPUT / OUTPUT SIGNAL Maximum support...

Integrated Stepper Electronics OPEN LOOP TYPE │ Integrated Open Loop 2-Phase Step Motor Drive Supporting Pulse input, RS-485 MODBUS-RTU, CANopen 42mm general step motor, Hollow shaft motor and all DINGS’ Linear actuators (E, N, C, K) Various parameters can be set through DINGS’ Tuner Pro GUI 2 differential inputs 2 digital inputs 1 digital output 4 digital inputs 1 digital output Pulse input RS-485 MODBUS-RTU Analog Speed Command 2 differential inputs 2 digital inputs 1 digital output 4 digital inputs 1 digital output 3 digital inputs 1 analog input BLDC · VCM Motor Speed Control Electronics...
