HPC070SC-FP6210
2Pages

Catalog excerpts

Industrial Panel PC Solution 7" WXGA Multi-Touch Panel PC With Fanless Intel® Celeron® Processor N6210 (formerly Elkhart Lake) Specifications SYSTEM PROCESSOR Intel® Celeron® Processor N6210 (formerly Elkhart Lake), 1.2 GHz (Dual-Core), Burst frequency 2.6GH SYSTEM MEMORY 1 x DDR4 3200 Single Channel SODIMM, Non-ECC (Max.32GB, up to 3200MHz) STORAGE DEVICE 1 x M.2 M-key 2280 for NVMe SSD (PCIe 3.0 x2) 1 x DB9 Serial RS-232 1 x RJ45 Serial RS-232/422/485 2 x USB3.2 Gen 1 1 x HDMI2.0 (Max. Resolution: 4096 x 2160@60Hz) 2 x RJ45 10/100/1000/2500 LAN 1 x DC-in 12~24V Jack (Lock type) 1 x Power Button + Power LED 1 x M.2 E-key 2230 (PCIe x1/USB2) (internal RP-SMA wires and Antenna pre-installed) Windows 10 (64bit), Windows 11 (enable PTT in BIOS) Linux VESA 75mm, Panel Mount CARTON DIMENSION GROSS WEIGHT OPERATING TEMPERATURE -10°C ~ 60°C (14°F ~ 140°F) with 0.5 m/s airflow STORAGE TEMPERATURE STORAGE HUMIDITY Meet CE/FCC Class A POWER SUPPLY INPUT Applications • Industrial Automation DISPLAY TYPE VIEWING ANGLE BACK LIGHT TOUCH SCREEN Packing List Description HPC070SC-FP6210 POWER-CORD (region specific) VESA Screws P-CAP Touchscreen LIGHT TRANSMISSION Aluminum Front Bezel + Metal Chassis ENVIRONMENT & CERTIFICATION • 7" WXGA (1024 x 600) LED Display • Projected Capacitive Multi Touch (P-CAP) • Aluminum Front Bezel • Fanless Intel® Celeron® Processor N6210 • Up to 32GB DDR4-3200, 2 x Intel 2.5GbE • HDMI-out for 2nd Display • VESA 75mm/Panel Mount Support • Support TPM2.0 (option) • DC-in 12~24V Part Number
